Chapter 3 Operation

3.1 The Front Section of IPC-603MB

3.1.1 Switches

Two switches are used for system power on-off and system reset. Press
the System Reset Switch to reinitialize the system. Press the Power On-
Off Switch to turn the system power on or off.

3.1.2 LED indicators

Two LEDs indicate the system status. Refer to Table 3-1 for the LED
summary.

Table 3.1: System Status LED Summary

LED
PWR
HDD
If the system is connected to a single power supply, the PWR LED is
always green while the power is on.
IPC-603MB User Manual
Description
System Power
Hard Drive Disk Activity
Green/Orange
Normal
Data Access
14
