pigtronix Infinity looper User Manual page 20

LOOP VOLUME 2 - Sets the Loop 1 output
volume
The Loop 1 and Loop 2 Volume knobs are
calibrated so that 12:00 = Unity Gain for Loop
audio. Turning either of the Loop Volume
knobs above 12:00 will result in Loop Audio
that is actually louder than the input signal.
Infinity Rules
Arm:
Arming a loop is done by pressing the footswitch
that corresponds to the desired loop. The Arm
light above the selected loop will glow red
indicating its status as armed. A loop must be
armed in order to accept further commands.
When the Infinity powers up initially, LOOP 1 is
armed by default. Loop 2 cannot be armed until
material is recorded on Loop 1,
Record:
Once a loop is armed, pressing the footswitch for
that loop will begin recording. The corresponding
loop LED will glow red to indicate recording. You
must record to Loop 1 first. You will be able to
record on Loop 2 once there is audio recorded
on Loop 1.
