Infinity Anatomy:
Jacks:
DC POWER 18-VOLTS – Use only the 18-Volt,
300mA, negative tip power supply that came
with your Pigtronix Infinity Looper.
Using the wrong power supply is likely to result
in a damaged pedal.
IN 1 – Looper input, Plug in your instrument
here.
IN 2 – Looper input, Plug in your instrument
here. When nothing is connected to IN 2, the
signal from IN 1 is automatically passed to IN 2.
OUT 1 – Effect output, ¼" TS cable. Amp,
mixer, or DI goes here.
OUT 2 - Effect output, ¼" TS cable. Amp, mixer,
or DI goes here.
AUX OUT – This output contains summed mono
audio of all currently playing loops.
output is primarily intended for use as a "loop
only" monitor send to a drummer, band mate
for FOH mixer.
UNDO – Connect a momentary remote switch
here using a ¼" TS cable to enable overdub
undo / redo.
This
