Footswitches:
LOOP 1 (ARM / PLAY / REC / DUB) – This
footswitch controls the looping actions for
Loop 1
LOOP 2 (ARM / PLAY / REC / DUB) – This
footswitch controls the looping actions for
Loop 2
STOP (HOLD = ERASE) – Pressing this footswitch
causes looped audio to stop playing. Holding
this footswitch down for 2 seconds causes
loop audio to be erased.
LEDs:
The Loop 1 and Loop 2 Footswitch LEDs share
the same color coding.
RED = Recording | GREEN = Playback |
ORANGE = Overdub
Both Loop 1 and Loop 2 Footswitch LEDs are
accompanied by a red square, "ARM" LED
that indicates which loop is currently armed.
When MIDI Sync is enabled, the ARM LED for
the currently selected Loop will blink at the
top of each measure to indicate that MIDI
sync is active.
STOP LED – The STOP LED will glow red when
loop audio is stopped.
