Monitoring

6-5
Monitoring
If PAT is used, the active port mappings are shown in the Monitor >
Networks > NAT/PAT > Port Assignments screen. Only those
mappings for the specified Remote Site will be displayed. This screen
shows the active port mappings for both TCP and UDP connections. Each
entry consists of the public and the private ports, the remote address and
port number, and the value of the inactivity timer.
For both NAT and PAT, the active address mappings are shown in the
Monitor > Networks > NAT/PAT > Mapped Addresses screen. Only
those mapping for the specified Remote Site will be displayed. This screen
shows the active private addresses, the associated public address, and the
number of active TCP and UDP connections. When PAT is configured,
each entry will have the same public address.
For more information on these monitoring screens, see "Monitoring the
OfficeConnect Remote 840" in Chapter 11.
