Advanced Configuration

The following flowchart provides an overview of the Advanced Configuration
submenus and the options for each setting.
Default
Cycle
MENU
CONTROL
MENU
OUTPUT
CONFIG
MENU
ADVANCED
NEXT
CONFIG

Top and bottom blanking

To remove noise or extraneous material, such as closed captioning, remove scan
lines at either the top or bottom of the screen. Rotate the horizontal Adjust (
knob to adjust the top blanking from 0 to 127 lines. The default is 0. Rotate the
vertical Adjust ( ) knob to adjust the bottom blanking from 0 to 127 lines. The
default is 0.

Blue mode

To aid in setup of the scaler's color and tint, the Blue mode can be set from this
submenu to "On" so that only sync and blue video signals are passed to the
display.
Use either the horizontal Adjust (
mode. The default is "Off".

Autoswitch (Autosw) mode

The Autoswitch mode causes the highest numbered input that has a signal
present to be automatically selected. For example, if both Inputs 1 and 2 have
active input signals, Input 2 is selected.
From this submenu, use either the horizontal Adjust (
knob to specify this mode as "On" or "Off". The default is "Off".
T BLNK B
NEXT
000 000
Top and bottom blanking
• Top blanking ranges from 000 (default)
to 127
• Bottom blanking ranges from 000 (default)
to 127
2:2 PLDN
NEXT NEXT
<OFF> ON
PAL film mode (2:2 pulldown detection)
• On
• Off (default)
) or vertical Adjust ( ) knob to specify this
IN1502 • Installation and Operation
BLUEMODE
NEXT
<OFF> ON
Display blue and sync only
• On
• Off (default)
AUTOSW
<OFF> ON
Autoswitch mode
• On
• Off (default)
) or vertical Adjust ( )
)
