Menu Descriptions

This section details the WSI menu pages, and briefly discusses the function of
each of the parameters available on each menu page.

Main Menu Bar

The WSI Main Menu Bar, shown in figure 3-2, allows configuring both the
modem and router functions of the target SLM-5650A Network Processor.
Note: The Vipersat menu item will only be displayed if the target SLM-5650A
NOTE
A Vipersat SLM-5650A is normally shipped from the factory with the Vipersat
FAST feature option already installed. This can be verified by checking that
Vipersat appears in the Main Menu bar, as shown in Figure 3-2. Alternatively,
this can be checked via the modem front panel under
Options
Each Main Menu item contains a nested submenu that will appear by perform-
ing a mouseover on that menu item. Clicking on a submenu item will open the
associated page.

Common Menu Commands

The following common menu commands are executed as described below.
C h a p t e r 3 - U s i n g t h e W e b S e r ve r I n t e r f a c e ( W S I )
has had the Vipersat option installed as described in the section "FAST
Features" on page 3-7.
.
Figure 3-2
Main Menu Bar
M e n u D e s c r i p t i o n s
Utility: FAST ->View
3-3
