Set the Home State

1.
2.
3.
4.
C h a p t e r 2 - Q u i c k S t a r t C o n f i g u r a t i o n
From the Vipersat submenu, select Home State to open the Home State
Configuration page (figure 2-10).
Click the Set Current Config As Home command button in the lower
portion of the page to set the current configuration as the Home State. This
pulls the current Tx and Rx settings of the base modem and displays them
here.
Figure 2-10
If any parameters require modifications, change the values then click the
Force Modem to Home State command button. This will push the home
state parameters that are displayed to the base modem.
Save the settings to flash by selecting Save from the Main Menu bar.
Home State Configuration Page
I n i t i a l C o n f i g u r a t io n
2-15
