I n i t i a l C o n f i gu r a t i o n

Initial Configuration

Note: Many of the settings required for equipment configuration are based on
NOTE

LAN Connection

For the purposes of this user guide, the configuration procedures are performed
using the WSI from a workstation connected to the modem's Network Proces-
sor (NP) via a LAN connection to one of the five available Ethernet ports:
• When operating as Router, the LAN connection should be to one of the
• When operating as BPM, connect to the J5 Ethernet port on the base
A web browser (e.g., Internet Explorer > 7.0, or Firefox > 2.0) provides the
application interface. Alternatively, other connection methods, as described in
the SLM-5650A Installation and Operation Manual, may be used to perform the
configuration.
Make a web connection by entering the target SLM-5650A NP IP address into
the browser address field. The factory default IP address for a Vipersat-enabled
unit is
5650A will respond with a Login prompt. The factory defaults are:
Following the operator login, the Network Processor web page splash screen is
displayed, as shown in figure 2-1. Across the top of the page, the Main Menu
bar is displayed.
2-2
the LAN/WAN and Satellite network design, and should be obtained from
the network administrator.
four traffic switched Ethernet ports (1–4) on the NP card.
modem.
192.168.1.177/24
Login: comtech
Password: comtech
. Once a web connection has been made, the SLM-
V i p e r s a t S L M - 5 6 5 0 A U s e r G u i d e
