Note: The following descriptions will refer to the SLM-5650A as either modula-
NOTE
Before enabling DPC, the operator should verify that a demodulator at another
terminal is receiving from this modulator, and that there is a working communi-
cations channel from that receiving station back to the modulator terminal
(In-Band communications). Additionally, since DPC controls potentially the
full power range of the modulator's output power, it is recommended that the
terminal be commissioned and calibrated before usage.
Tip: The DPC feature will not function unless the Outbound IP address is

Dynamic Power Control

The DPC feature can be set to either Enabled or Disabled using the pull-down
menu. The SLM-5650A is shipped with DPC turned off (Disabled) to allow
entrance link levels calibration during terminal setup.
To activate DPC for this modem, select Enabled then click the Submit button.

Target Eb/No

The Target E
control and is set in the transmit modem. This is the value used for comparison
with the actual E
by the transmitting terminal for output power level adjustment as necessary.
To modify this parameter, enter a value from 0.0–15.0 dB, then click the
Submit button. The default value is 10.0 dB.
C h a p t e r 3 - U s i n g t h e W e b S e r ve r I n t e r f a c e ( W S I )
Figure 3-42
tor or demodulator for simplicity and understanding.
defined in the STDMA screen for the Hub BC modem. See page 3-21.
/N is the desired operating receive level for closed loop servo
b 0
/N from the receiving modem. This information is processed
b 0
DPC Configuration (Hub Expansion Demod)
V i p e r s a t C o n f i g u r a t io n
3-35
