SWITCHES ON DRIVER'S DOOR TRIM

OUTSIDE REARVIEW MIRROR CONTROL SWITCH

Outside rearview mirror
control switch
Window lock
switch
Central
door lock/unlock switch
CAUTION
• Do not fold or unfold the outside rearview mirrors manually. It may
cause a malfunction of the mirror folding system.
• If the outside rearview mirrors are folded or unfolded manually, an
abnormal noise may be produced during the folding switch operations.
• If you operate the outside rearview mirror folding switch within 10
seconds after starting the recognizing operation of the mirror position,
continuous abnormal noise may be produced.
4 - 1 6
INTERIOR SWITCHES
Window operation
switches
3. Aiming switch
Adjust the selected mirror up, down, left, or right by press-
ing the corresponding edges of the switch to get the di-
rect rearview.
Recognizing Operation of the Mirror Position
When you folded or unfolded the outside rearview mirrors,
perform the recognizing operation of the mirror position in
the following order.
1. Fold/unfold the mirrors with folding switch.
2. The mirrors are folded/unfolded.
3. Fold/unfold the mirrors with folding switch after 10 seconds.
4. The mirrors are folded/unfolded.
5. The mirrors can be operated with folding switch after 10
seconds.
1. Outside rearview mirror
folding switch
To fold the outside rearview
mirrors, press the switch for
more than 0.5 seconds. To
unfold the mirrors, press
again.
2. Mirror selection switch
"L": Driver side mirror
"R": Passenger side mirror
"•": Neutral position
