Ofrecido por www.electromanuales.com
OFF switch
Fan Control Switch
The fan speed can be adjusted in 4 stages.
CAUTION
If the air conditioner switch is turned off, the air conditioner does
not work even when the fan switch is operated. However, the air
flows due to fan operation.
VENTILATION, HEATING, AIR CONDITIONING AND AIR PURIFICATION SYSTEM
4 stages
Cool
Temperature
Control Switch
Adjust the temperature of flowing air by turning the dial.
Red direction: Hot
Blue direction: Cool
White direction: Bi_level zone
Hot
9-7
