7. Loosen the wheel nuts one or two turns by turning counter-
clockwise with the wheel nut wrench. Do not remove the
wheel nuts until the tyre is off the ground.
12-8
IN CASE OF EMERGENCY
Rear jack up point
Front jack up point
8. Place the jack directly under the jack-up points so that top
of the jack contacts the vehicle at the jack-up point. Align
the center of both the jack head and the jack-up point by
turning the connecting ring with hands.
WARNING
Do not attempt to raise the vehicle until the jack is in the proper
position, and secure both to the vehicle and the ground. It may cause
a persona; injury or a vehicle damage.
• Locate the jack at
a correct jack-up
point.
• The jack-up point
is reinforced. Be-
fore setting up the
jack, check the
jack-up point by
hands.
Jack head
1
2 Base plate
