1.2 Typical System Installation
Figure 1-2
public address system.
Loudspeaker Amplifier
Operations Guide
illustrates how the VoIP V2 Loudspeaker Amplifier is normally installed as part of a
Figure 1-2. Typical Installation
802.3af Compliant Ethernet Switch
1
PoE Injector
(High Power Mode with Injector)
Loudspeaker Amplifier
2
3
4
5
6
VoIP Phone
930377C
Product Overview
Typical System Installation
Informacast Server
