Table 6-3. Information on the Virtual Disk Management Screen
Menu Item Selected
in Left Panel
Physical Disks
Physical Disk #
Total Free Capacity Disk Group # Properties:
102
Configuring and Managing RAID
Information Displayed in Right Panel
Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
• Number of free segments
• Number of dedicated hot spares
Physical Disk Properties:
• Vendor name
• Physical disk state
• Enclosure Position
• Slot Position
Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
• Number of free segments
• Number of dedicated hot spares
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
• Number of free segments
• Number of dedicated hot spares
(continued)
