Figure 4-5. Removing the PERC H800 Adapter
1 bracket screw
3 battery
5 PERC H800 Adapter
5 Disconnect the data cables and battery cable from the PERC H700.
Remove any retention mechanism, such as a bracket screw, that might
be holding the PERC H700 in the system, and gently lift the controller
from the system's PCI-E slot.
1
2
2 memory module
4 Dirty Cache LED
Installing and Configuring Hardware
3
4
5
