To create a CacheCade virtual disk:
1 During host system bootup, press <Ctrl><R> when the BIOS screen is
displayed.
The Virtual Disk Management screen is displayed. If there are more than
one controller, the main menu screen is displayed.
2 Select a controller, and press <Enter>.
The Virtual Disk Management screen is displayed for the selected
controller.
3 Use the arrow keys to highlight Controller #.
4 Press <F2>.
The list of available actions is displayed.
5 Select Create CacheCade Virtual Disk and press <Enter>.
The Create CacheCade Virtual Disk screen is displayed. The cursor is on
the first SSD listed in the Select SSD section.
6 Select the desired SSD(s). As each new SSD is selected, the CacheCade
Virtual Disk Size changes to reflect the new size.
NOTE:
7 Press <Tab> to move the cursor to the CacheCade Virtual Disk Name
field. Enter a name if required.
8 After you specify the virtual disk name, select OK to save the selection or
select Cancel to cancel the selection.
After the CacheCade virtual disk is created successfully, it is listed in the
Virtual Disk Management screen under the CacheCade disk group, and is
labeled as a CacheCade virtual disk. The virtual disk has an optimal state and
its RAID level is RAID 0.
NOTE:
You can only delete or rename a CacheCade virtual disk. Background
Initialization, fast initialization, full initialization, and consistency check operations
are not applicable to CacheCade virtual disks.
You cannot specify the size of the virtual disk.
