Table 6-3. Information on the Virtual Disk Management Screen
Menu Item Selected
in Left Panel
Disk Group #
Virtual Disks
Virtual Disk #
Information Displayed in Right Panel
Disk Group # Properties:
• Number of virtual disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
• Number of free segments
• Number of dedicated hot spares
• Security property of the Disk Group
Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available in the virtual disk
• Number of free segments
• Number of dedicated hot spares
Virtual Disk # Properties:
• RAID level (0, 1, 5, 6, 10, 50, or 60)
• RAID status of the virtual disk (Failed, Degraded, Partially
Degraded, or Optimal)
• Operation currently in progress
Disk Group # Properties:
• Number of virtuals disks (VD)
• Number of physical disks (PD)
• Space available on the physical disks
• Number of free segments
• Number of dedicated hot spares
Configuring and Managing RAID
(continued)
