[0~61440]
spanning-tree priority
[seconds]
spanning-tree max-age
[seconds]
spanning-tree hello-time
spanning-tree forward-time
stp-path-cost
[1~200000000]
stp-path-priority
[Port Priority]
stp-admin-p2p
[Auto|True|False]
stp-admin-edge
[True|False]
stp-admin-non-stp
[True|False]
show spanning-tree
no spanning-tree
3.2.8

QOS Commands Set

Table 3.8: QOS Commands Set
Commands
qos policy
[weighted-fair|strict]
qos prioritytype
[port-based|cos-only|tos-only|cos-
first|tos-first]
qos priority portbased
[Port] [lowest|low|middle|high]
qos priority cos
[Priority][lowest|low|middle|high]
qos priority tos
[Priority][lowest|low|middle|high]
Configure spanning tree priority
G
parameter
Use the spanning-tree max-age
global configuration command to
change the interval between
messages the spanning tree
receives from the root switch. If a
switch does not receive a bridge
G
protocol data unit (BPDU)
message from the root switch
within this interval, it recomputed
the Spanning Tree Protocol (STP)
topology.
Use the spanning-tree hello-time
global configuration command to
specify the interval between hello
G
bridge protocol data units
(BPDUs).
[seconds] Use the spanning-tree forward-
time global configuration command
to set the forwarding-time for the
specified spanning-tree instances.
G
The forwarding time determines
how long each of the listening and
learning states last before the port
begins forwarding.
Use the spanning-tree cost
interface configuration command
to set the path cost for Spanning
Tree
Protocol (STP) calculations. In the
I
event of a loop, spanning tree
considers the path cost when
selecting
an interface to place into the
forwarding state.
Use the spanning-tree port-priority
interface configuration command
to configure a port priority that
I
is used when two switches tie for
position as the root switch.
Admin P2P of STP priority on this
I
interface.
Admin Edge of STP priority on this
I
interface.
Admin NonSTP of STP priority on
I
this interface.
Displays a summary of the
E
spanning-tree states.
Disable spanning-tree.
G
Level
Select QOS policy scheduling
G
Setting of QOS priority type
G
Configure Port-based Priority
G
Configure COS Priority
G
Configure TOS Priority
G
39
switch(config)#spanning-tree priority 32767
switch(config)#spanning-tree max-age 15
switch(config)#spanning-tree hello-time 3
switch(config)#spanning-tree forward-time 20
switch(config)#interface fastEthernet 2
switch(config-if)#stp-path-cost 20
switch(config)#interface fastEthernet 2
switch(config-if)#stp-path-priority 128
switch(config)#interface fastEthernet 2
switch(config-if)#stp-admin-p2p Auto
switch(config)#interface fastEthernet 2
switch(config-if)#stp-admin-edge True
switch(config)#interface fastEthernet 2
switch(config-if)#stp-admin-non-stp False
switch>show spanning-tree
switch(config)#no spanning-tree
Description
switch(config)#qos policy weighted-fair
switch(config)#qos prioritytype
switch(config)#qos priority portbased 1 low
switch(config)#qos priority cos 0 middle
switch(config)#qos priority tos 3 high
Example
Chapter3
