Page 1: User Manual
EKI-4524I 24-port 10/100TX Ethernet Switch with AC/DC Power Input User Manual... - Page 2 The documentation and the software included with this product are copyrighted 2011 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 Because of Advantech′s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 Step 2. Contact your distributor, sales representative, or Advantech’s customer service center for technical support if you need additional assistance. Please have the following information ready before you call: - Product name and serial number...
- Page 5 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
- Page 6 Safety Precaution - Static Electricity Follow these simple precautions to protect yourself from harm and the products from damage. 1. To avoid electrical shock, always disconnect the power from your equipment chassis before you work on it. 2. Disconnect power before making any configuration changes. EKI-4524I_User Manual...
-
Page 7: Table Of Contents
Installation........8 2.1 LED Indicators ............ 8 Table 2.1: EKI-4524I LED Definition........8 2.2 Dimensions (units: mm) ........9 Figure 2.1: EKI-4524I Mechanical Dimensions ......9 2.3 Mounting ............10 2.3.1 Rack mounting......... 10 Figure 2.2: Attach mounting brackets with screws....10 Figure 2.3: Mount the switch in the 19” rack ......10 2.4 Network Connection ......... - Page 8 EKI-4524I_User Manual viii...
-
Page 9: Chapter 1 Overview
Overview Sections include: Introduction Features Specifications Packing List Safety Precaution Chapter1... -
Page 10: Introduction
1.1.2 19” Rack Mounting The EKI-4524I comes with a rack-mounted kit and can be mounted in an EIA standard size, 19-inch Rack. The Switch can be placed in a wiring closet with other equipment. 1.1.3 Advanced Protection... -
Page 11: Features
1.2 Features • System Interface/Performance RJ-45 ports support Auto MDI/MDI-X Function Store-and-Forward Switching Architecture Back-plane (Switching Fabric): 4.8Gbps 4Mbits Packet Buffer 8K MAC Address Table • Power Supply 100 ~ 240 V , 50/60Hz 100 ~ 240 V • Case/Installation IP-30 Protection 19-inch Rack-Mount Design •... -
Page 12: Specifications
1.3 Specifications Communications IEEE 802.3, 802.3u, 802.3x IEEE Standard 10/100Base-TX Up to 100m Transmission Distance 10/100Mbps, Auto-Negotiation Transmission Speed Interface 24 x RJ-45 Connectors 10-pin barrier terminal block System: PWR LED Indicators 10/100TX: LNK/ACT, Speed Power 14.5 Watts max. @ 110 V Power Consumption 11.04 Watts max. - Page 13 Certifications CE, FCC Class A IEC60068-2-32 Freefall IEC60068-2-27 Shock IEC60068-2-6 Vibration Chapter1...
-
Page 14: Packing List
1.4 Packing List • 1 x EKI-4524I Industrial Unmanaged Fast Ethernet Switch • 1 x eAutomation Industrial Communication CD-ROM and User manual • 2 x Rack Mounting Bracket and Screws • 1 x EKI-4524I Startup Manual 1.5 Safety Precaution Attention IF DC voltage is supplied by an external circuit, please use a protection device on the power supply input. -
Page 15: Chapter 2 Installation
Installation Sections include: LED Indicators Dimensions Mounting Network Connection Wiring Power Input Wiring Relay Alarm Chapter2... -
Page 16: Table 2.1: Eki-4524I Led Definition
In this chapter, you will be given an overview of the EKI-4524I hardware installation procedures. 2.1 LED Indicators The LED indicators located on the panel display the power status and network status of EKI-4524I; each has its own specific meaning as the table shown below. -
Page 17: Dimensions (Units: Mm)
2.2 Dimensions (units: mm) 44.00 440.00 Figure 2.1: EKI-4524I Mechanical Dimensions Chapter2... -
Page 18: Mounting
Figure 2.2: Attach mounting brackets with screws 2. After attaching the mounting brackets, position the EKI-4524I in the rack by lining up the holes in the brackets with the appropriate holes on the rack. Secure the Switch to the rack by a screwdriver with the rack-mounting screws. -
Page 19: Network Connection
Network Connection The EKI-4524I has 24 x RJ-45 ports that support connection to 10 Mbps Ethernet, or 100 Mbps Fast Ethernet, and half or full duplex operation. EKI-4524I can be connected to other hubs or switches via a twisted-pair straight-through or crossover cable up to 100m long. The connection can be made from any TX port of the EKI-4524I (MDI-X) to another hub or switch either MDI-X or uplink MDI port. -
Page 20: Wiring Power Input
2.5 Wiring Power Input EKI-4524I comes equipped with a 10-position corss screw terminal block on where power input and fail- safe relay are located. Please follow the steps below to wire the power connection. Table 2.2: Terminal Block Pinouts Description... -
Page 21: Wiring Relay Alarm Contacts
Close circuit formed by wiring with an external power and an alarm device (a buzzer or a flashing LED), system will detect the power failure event. If a failure event occurs, the relay inside EKI-4524I will act as an open switch, and therefore break the external circuit. The fail-safe design is intended for triggering the connected alarm device for warning purposes. - Page 22 EKI-4524I_User Manual...
-
Page 23: Chapter 3 Troubleshooting
Troubleshooting... - Page 24 Chapter 3 Troubleshooting Verify that you are using the right power cord/adapter. Please don’t use a power adapter with DC outputs higher than the power rating of this equipment, or it will be damaged. Select the proper UTP cable to construct the user network. Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100Ω...
-
Page 25: Appendix A Pin Assignments & Wiring
Pin Assignments & Wiring... -
Page 26: Figure A.1: Rj-45 Pin Assignments
Appendix A Pin Assignments & Wiring It is suggested to adopt ELA/TIA as the wiring of the RJ-45. Figure A.1: RJ-45 Pin Assignments Figure A.2: EIA/TIA-568B Figure A.2: EIA/TIA-568A EKI-4524I_User Manual...
