Chapter 1-Hardware Description
1-24

RTM ISDN 1500 LEDs

The following LEDs appear on the RTM ISDN:
Table 1-11 RTM ISDN 1500 LEDs
Function Name LED Color
PRI (1-4) LEDs OFF
Green
Red

Power Supply LEDs

The following items appear on the rear panel power supply:
Table 1-12 Power Supply LED's
Component LED ID
Power Statuses OK
Alarm
AC
Indication
Span x not in use.
Span x is OK.
Span x red alarm (LOS - Loss of Signal)
LED Color Indication
Green OK.
Amber PS Fail - Problem with power
supply. This amber LED is driven
by internal circuitry and will
illuminate when a power rail has
failed.
Green When the power cable is plugged-
in, the AC LED becomes lit.
