Page 1: Hardware Guide
Polycom 1500 ® ® Hardware Guide Version 7.0 | August 2010 DOC2557A... - Page 2 (e.g., a book or sound recording). Every effort has been made to ensure that the information in this manual is accurate. Polycom, Inc., is not responsible for printing or clerical errors. Information in this document is subject to change...
-
Page 3: Table Of Contents
RMX 1500 Rear Panel LEDs ... 1-17 RTM IP 1500 LEDs ... 1-17 RTM ISDN 1500 LEDS ... 1-19 Power Supply LEDs ... 1-19 Installing the RTM ISDN 1500 Card ... 2-2 Replacing the RTM ISDN 1500 ... 2-5 Polycom RMX 1500 Hardware Guide... - Page 4 Table of Contents...
-
Page 5: Hardware Description
This Hardware Guide provides information on the RMX 1500 and its components. This system utilizes a modular platform, whose components are designed for high performance, capacity and reliance. Main Features The Polycom RMX 1500 offers the following features: • Linux® based •... -
Page 6: Rmx 1500 Specifications
Environment Operating temperature Storage temperature Relative humidity Operating altitude Operating ESD Polycom RMX 1500 Specifications 1U (4.44 cm.) 19” (48.26 cm.) 23.6” (60 cm.) Up to 12 Kg. G.711, G. 719, G.722, G.722.1, G.729A, G.723.1, Siren14, Siren 22. H.261, H.263, H.264. -
Page 7: Rmx 1500 System Capacities
Maximum number of CDR Files Maximum number of Fault Files Number of Participant alerts Maximum number of concurrent RMX Web Client connections to the MCU System Functions and Capacities RMX 1500 Polycom RMX 1500 Hardware Guide Capacity 1000 20 (default) 4000 2000... - Page 8 Chapter 1-Hardware Description Table 1-2 System Functions Maximum number of Users Maximum number Address Book entries Maximum number of gateway profiles Maximum number of Reservations (Internal Scheduler) Table 1-3 Video Resolution HD Support PSTN VOIP ISDN CIF H.263 CIF H.264 4CIF 720p30 1080p30fps/720p60...
-
Page 9: Site Requirements
You will also need it placed near a grounded power outlet. • Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with the full weight of the rack resting on them. Polycom RMX 1500 Hardware Guide... -
Page 10: Installation Precautions
Chapter 1-Hardware Description • In a single rack installation, stabilizers should be attached to the rack. • In multiple rack installations, the racks should be coupled together. • Always make sure the rack is stable before extending a component from the rack. •... -
Page 11: Connecting The Rmx 1500 To A Power Source
Do not connect the green or green-yellow wire to the system single-point ground screw. • Only the AC Power cable supplied by Polycom should be used. • The size of the protective earthing conductor should be a minimum of 10AWG. -
Page 12: Connecting Cables On The Rmx 1500
Chapter 1-Hardware Description Connecting Cables on the RMX 1500 To connect the cables: • For the RTM-IP 1500 module: — Connect the Media cable to LAN 2 port. — Connect the Network cables to the MNG (Signaling) port & — (Optional) Connect the Shelf Management cable to the Shelf port. •... - Page 13 Polycom RMX 1500 Hardware Guide The parameters in the lan.cfg file are uploaded from the USB key to the RMX’s memory and applied during the power-up sequence. System power-up sequence may take up to five minutes. During the First-time Power-up the red ERROR LED on the RMX’s front panel remains ON until both the Management and IP Network Services have been defined.
-
Page 14: Rmx 1500 Components
RMX 1500 Components On the RMX 1500, components are located on both the front and rear of the MCU as listed in Table 1-4, "Polycom RMX 1500 Front Panel Description". For more information see the descriptions of the "RMX 1500 Front Panel”... -
Page 15: Front Panel Components
Front Panel Components USB Slot VGA Slot Figure 1-2 RMX 1500 Front Panel Table 1-4 Polycom RMX 1500 Front Panel Description SLOT/Button/ Description USB Slot USB key connection, used for First time configuration. VGA Slot Monitor connection. Keyboard Slot Keyboard connection. -
Page 16: Rmx 1500 Rear Panel
Chapter 1-Hardware Description RMX 1500 Rear Panel The RMX 1500 rear panel contains the RTM IP 1500 and optionally, the RTM ISDN 1500. In addition, the rear panel houses the power supply with fan & AC inlet, and Serial port. Power Supply with built in Fan RTM IP 1500... - Page 17 Selection of the connection type for the RS-232 Port. When the switch is up - the serial port connects to the MPMx card. When the switch is down, connects to the RTM IP. Polycom RMX 1500 Hardware Guide Modem Serial Shelf...
-
Page 18: Rtm Isdn 1500
Chapter 1-Hardware Description Table 1-5 Item Standby button RTM ISDN 1500 The RTM ISDN 1500 connects directly to the built-in MPMx. The RTM ISDN card routes data between the MPMx card and components of the system, converts ISDN T1/E1 media to IP packets and provides connectivity to external ISDN networks. -
Page 19: Isdn/Pstn Clock Source
On the RMX 1500 there are three LEDs that indicate the power status. Table 1-6 Power Supply LED (Alarm symbol) AC/~ (symbol) Polycom RMX 1500 Power Supply LEDs Description DC power indication to internal components of the RMX: Green - DC Power Good. Power supply failure Indication: Amber - Power Supply Failure. -
Page 20: Rmx 1500 Leds
Chapter 1-Hardware Description RMX 1500 LEDs The RMX includes LEDs located on the front panel and rear panel. In the front panel, the LEDs reflect the state of the components. The LEDs on the rear panel indicate the state of the external connections and the status of the RTM IP card. -
Page 21: Rmx 1500 Rear Panel Leds
Green 1 Gb Amber Green 1 Gb Amber Green Amber Polycom RMX 1500 Hardware Guide Indication ON with an active network connection, flickers with Packet activity. ON with a 1Gb online connection, flickers with Packet activity. ON with an active network connection, flickers with Packet activity. - Page 22 Chapter 1-Hardware Description Table 1-8 Component Modem Additional LEDs 1-18 RTM IP 1500 LEDs (Continued) LED Color Name Green Amber STBY Green Green Indication ON with an active network connection, flickers with activity. ON when the active network is 10/100Mb, flickers with activity. ON - Major error on RTM IP 1500.
-
Page 23: Rtm Isdn 1500 Leds
The following items appear on the rear panel power supply: Table 1-10 Power Supply LED’s Component LED ID Power Statuses Alarm Polycom RMX 1500 Hardware Guide LED Color Indication Green ON with an active network connection, flickers with Packet activity. - Page 24 Chapter 1-Hardware Description 1-20...
-
Page 25: Component Installation & Replacement
Component Installation & Replacement On the RMX 1500 you can install and replace the RTM ISDN 1500 card. For more information see, "Installing the RTM ISDN 1500 Card” on page 2-2. Before installing a parts: • Make sure you have the correct replacement part on hand. •... -
Page 26: Installing The Rtm Isdn 1500 Card
Chapter 2- Component Installation & Replacement Installing the RTM ISDN 1500 Card Prior to adding the RTM ISDN 1500 card you must have your ISDN product license available. For more information see, RMX 1500/2000/ Getting Started Guide, "Procedure 2: Product Registration” on page 2-20. Ensure that the power switch on the RMX 1500 is turned OFF (O). - Page 27 Polycom RMX 1500 Hardware Guide Connect the PRI cables. Turn ON the RMX 1500. Login on to the RMX Web Client. 4 E1/T1 connections Update your license. For more information see, RMX 1500/2000/ Getting Started Guide, Chapter 2, “Procedure 2: Product Registration”...
-
Page 28: Component Replacement
Chapter 2- Component Installation & Replacement Component Replacement The RMX 1500 is designed with ease of maintenance in mind. Most components are swappable and are accessible directly via the front panel or the rear panel. The following component can be replaced when it is faulty: The RTM-IP 1500 and Power Supply are not field replaceable. -
Page 29: Replacing The Rtm Isdn 1500
Polycom RMX 1500 Hardware Guide Replacing the RTM ISDN 1500 Ensure that the power switch on the RMX 1500 is turned OFF (O). Remove the PRI cables. Loosen the captive screws that fasten the card to the MCU. Remove the RTM ISDN card and pull the RTM ISDN card out of its slot in the backplane.
