Standard Horizon MATRIX GX2100 Owner's Manual

Matrix series 25 watt vhf/fm marine transceivers
Hide thumbs Also See for MATRIX GX2100:
Table of Contents

Advertisement

Quick Links

MATRIX SERIES
GX2000 and GX2100
25 Watt VHF/FM
Marine Transceivers
Owner's Manual
Integrated dual channel AIS (Automatic Identification System) receiver (GX2100)
AIS (Automatic Identification System) receiver or transponder connection (GX2000)
AIS target display: MMSI. Call Sign, Ship Name, BRG, DST, SOG, and COG
Contact AIS Ship with DSC*
38400 AIS VDM sentence output to compatible GPS Chart Plotter (GX2100)
80 dB Commercial grade receiver
Class D DSC (Digital Selective Calling) with Individual, All Ship, Position Report, Posi-
tion Request, and Distress.
Automatically poll up to 4 ships
Independent Channel 70 receiver built-in for continuous DSC watch
Local/Distance attenuator
Enter, Save, and Navigation to waypoint with Compass page
Navigation to a DSC Distress Call
Submersible JIS-7 / IPX7 (3.3 feet for 30 minutes)
ClearVoice noise canceling speaker microphone with channel selection and 16/9 key
Oversized rotary channel knob with push to enter, backlit display and keys
30 Watt PA/Loud Hailer with pre-programmed fog signals and (listen back GX2100)
Capable of connecting an optional RAM3 second station remote microphone
Intercom between radio and RAM3
DSC position request and report function when connected to compatible GPS chart
plotter
Voice Scrambler (optional)
One button access to Channel 16 and 9
User programmable soft keys
Navigation (LAT/LON, SOG, and COG) information shown on display
E2O (Easy-To-Operate) menu system
When connected to an optional GPS (GX2100)
When connected to an optional GPS and AIS receiver or transponder (GX2000)
MATRIX AIS GX2100
MATRIX GX2000
GX2000/GX2100
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MATRIX GX2100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Standard Horizon MATRIX GX2100

Summary of Contents for Standard Horizon MATRIX GX2100

  • Page 1 MATRIX SERIES GX2000 and GX2100 25 Watt VHF/FM Marine Transceivers Owner's Manual Integrated dual channel AIS (Automatic Identification System) receiver (GX2100) AIS (Automatic Identification System) receiver or transponder connection (GX2000) AIS target display: MMSI. Call Sign, Ship Name, BRG, DST, SOG, and COG Contact AIS Ship with DSC* 38400 AIS VDM sentence output to compatible GPS Chart Plotter (GX2100) 80 dB Commercial grade receiver...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Quick Reference Guide ..............................4 GENERAL INFORMATION ............................. 8 PACKING LIST ............................... 9 OPTIONS ................................. 9 SAFETY/WARNING INFORMATION ........................10 FCC RADIO LICENSE INFORMATION ......................11 FCC NOTICE ................................ 12 GETTING STARTED ............................13 PROHIBITED COMMUNICATION ......................13 ABOUT VHF RADIO ..........................
  • Page 3 TABLE OF CONTENTS 11.8 POSITION REQUEST ..........................67 11.8.1 Setting up a Position Reply ....................67 11.8.2 Setting up a Position Request Ringer ................68 11.8.3 Transmitting a Position Request to Another Vessel ............68 11.8.4 Receiving a Position Request ....................69 11.9 POSITION REPORT ..........................

  • Page 4: Quick Reference Guide

    PWR/VOL K Press and hold this knob to turn on or off the radio. When the radio is on, turning CH/ENTER K this knob will adjust the speaker audio Selects the operating channel. volume. 16/9 B H/L B SQL K Press to recall chan- W h e n p r e s s e d ,...
  • Page 5 The 3 soft keys under- CH/ENTER K neath the display can be customized, refer Selects a Marine DISTRESS B t o s e c t i o n “ 1 2 . 1 2 V H F o r N O A A SOFT KEYS”.
  • Page 6 ELECTRICAL CONNECTIONS PA Speaker Shield GPS Receiver NMEA COMMON AIS Receiver Note: HS = 38400 baud White External Speaker Shield MATRIX GX2000 PA Speaker Shield GPS Receiver Radio Wires Plotter Connection Gray: NMEA Output ( ) NMEA IN ( ) Blue: NMEA Input ( ) NMEA OUT ( ) NMEA COMMON ( )
  • Page 7 DESKTOP/OVERHEAD MOUNTING THE RADIO The supplied universal mounting bracket allows desktop or overhead mounting. Use a 13/64” (5.2-mm) bit to drill the holes to a surface which is more 0.4 inch (10 mm) thick and can support more than 3.3 lbs (1.5 kg) and secure the bracket with the supplied screws, spring washers, flat washers, and nuts.

  • Page 8: General Information

    1 GENERAL INFORMATION 1.1 INTRODUCTION The STANDARD HORIZON MATRIX Series GX2000 and GX2100 Marine VHF/ FM Marine transceiver are designed to be used in USA, International and Ca- nadian Marine bands. The GX2000 and GX2100 can be operated from 11 to 16 VDC and has a switchable RF output power of 1 watt or 25 watts.

  • Page 9: Packing List

    2 PACKING LIST When the package containing the transceiver is first opened, please check it for the following contents: GX2000 or GX2100 Transceiver Mounting Bracket and hardware Owner’s Manual DSC Warning Sticker Flush Mount Template Power Cord 3 OPTIONS MMB-84 ................. Flush-Mount Bracket CMP30B/W ....

  • Page 10: Safety/Warning Information

    PRODUCT SUPPORT INQUIRIES If you have any questions or comments regarding the use of the GX2000/ GX2100, you can visit the STANDARD HORIZON Web site to send an E-Mail or contact the Product Support team at (800) 767-2450 M-F 7:00- 5:00PST.

  • Page 11: Fcc Radio License Information

    5 FCC RADIO LICENSE INFORMATION Standard Horizon radios comply with the Federal Communication Commis- sion (FCC) requirements that regulate the Maritime Radio Service. STATION LICENSE An FCC ship station license is no longer required for any vessel traveling in U.S. waters (except Hawaii) which is under 20 meters in length. However, any...

  • Page 12: Fcc Notice

    Unauthorized changes or modifications to this equipment may void com- pliance with FCC Rules. Any change or modification must be approved in writing by STANDARD HORIZON. NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 13: Getting Started

    7 GETTING STARTED PROHIBITED COMMUNICATIONS The FCC prohibits the following communications: • False distress or emergency messages: • Messages to “any boat” except in emergencies and radio tests; • Messages to or from a vessel on land; • Transmission while on land; •...

  • Page 14: Coaxial Cable

    COAXIAL CABLE VHF antennas are connected to the transceiver by means of a coaxial cable – a shielded transmission line. Coaxial cable is specified by it’s diameter and construction. For runs less than 20 feet, RG-58/U, about 1/4 inch in diameter is a good choice.

  • Page 15: Emergency Channel 16 Use

    EMERGENCY CHANNEL 16 USE Channel 16 is known as the Hail and Distress Channel. An emergency may be defined as a threat to life or property. In such instances, be sure the transceiver is on and set to CHANNEL 16. Then use the following procedure: 1.

  • Page 16: Calling Another Vessel (Channel 16 Or 9)

    CALLING ANOTHER VESSEL CHANNEL 16 OR 9 Channel 16 may be used for initial contact (hailing) with another vessel. However, its most important use is for emergency messages. This channel must be monitored at all times except when actually using another channel. It is monitored by the U.S.

  • Page 17: Making Telephone Calls

    MAKING TELEPHONE CALLS To make a radiotelephone call, use a channel designated for this purpose, The fastest way to learn which channels are used for radiotelephone traffic is to ask at a local marina. Channels available for such traffic are designated Pub- lic Correspondence channels on the channel charts in this manual.

  • Page 18: Installation

    8 INSTALLATION LOCATION The radio can be mounted at any angle. Choose a mounting location that: • is far enough from any compass to avoid any deviation in compass read- ing due to the speaker magnet • provides accessibility to the front panel controls •...
  • Page 19 8.2.2 Optional MMB-84 Flush Mount Bracket 1. Make a rectangular template for the flush mount measuring 2.6” H x 6.3” W (65 x 161 mm). 2. Use the template to mark the location where the rectangular hole is to be cut.

  • Page 20: Electrical Connections

    ELECTRICAL CONNECTIONS CAUTION Reverse polarity battery connections will damage the radio! Connect the power cord and antenna to the radio. Antenna and Power Supply connections are as follows: 1. Mount the antenna at least 3 feet (1 m) away from the radio. At the rear of the radio, connect the antenna cable.

  • Page 21: Accessory Cable

    ACCESSORY CABLE 8.4.1 MATRIX GX2000 Connection PA Speaker Shield GPS Receiver NMEA COMMON AIS Receiver Note: HS = 38400 baud White External Speaker Shield Wire Color/Description Connection Examples WHITE - External Speaker ( + ) Connect to external 4 Ohm audio speaker SHIELD - External Speaker (–) Connect to external 4 Ohm audio speaker RED - PA Speaker ( + )
  • Page 22 When connecting the external speaker or GPS navigation receiver, strip off about 1 inch (2.5 cm) of the specified wire’s insulation, then splice the ends together. Note: In some areas powerful AM broadcast stations may be heard when in listen-back mode. In this case change the speaker wire to 2-conductor shielded audio cable.

  • Page 23: Checking Gps Connections

    CHECKING GPS CONNECTIONS After connections have been made between the GX2000/GX2100 and the GPS, a small satellite icon will appear on the top right corner of the display and your current location (Latitude/Longitude) is shown on the display. NOTE If there is a problem with the NMEA connection between the radio and the GPS, the GPS icon will blink continuously until the connection is corrected.

  • Page 24: Changing The Time Location

    CHANGING THE TIME LOCATION This menu selection allows the radio to show UTC time or local time with the offset. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears, then select “GENERAL SETUP” with the CHANNEL knob.

  • Page 25: Changing Cog To True Or Magnetic

    CHANGING COG TO TRUE OR MAGNETIC Allows the GPS Course Over Ground to be selected to show in True or Mag- netic. Factory default is True however by following the steps below the COG can be changed to Magnetic. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 26: Optional Cmp30 Ram3 Installation

    8.10 OPTIONAL CMP30 RAM3 INSTALLATION The GX2000/GX2100 is capable of using a CMP30 ( RAM3 ) Remote Station Microphone to remotely control the Radio, AIS, DSC and PA/Fog functions. In addition the GX2000/GX2100 can operate as a full function intercom system between the RAM3 and the radio.
  • Page 27 Connecting an External Speaker to the RAM3 Mic Cable In noisy locations and optional external speaker may be connected to the white speaker wires on the RAM3 routing cable. The RAM3 can drive the internal speaker or the external speaker one at a time. When connecting an external speaker, follow the procedure below to turn off the RAM3 audio and enable the external speaker wires on the RAM3 routing cable.

  • Page 28: Controls And Indicators

    9 CONTROLS AND INDICATORS NOTE This section defines each control of the transceiver. See illustration at the next page for location of controls. For detailed operating instructions refer to chapter 10 of this manual. CONTROLS AND CONNECTIONS CHANNEL Knob Rotary knob is used to select channels and to choose menu items (such as the DSC menu, Radio Setup and DSC Setup menu).
  • Page 29 Never remove this rubber cap. When this rubber cap is re- moved, the water resistance performance is lost. GX2000/GX2100 Page 29...
  • Page 30 Soft Keys The 3 soft keys functions can be customized by the Setup Menu mode section “12.12 SOFT KEYS”. When one of the soft keys is pressed briefly, the functions will appear above each key on the display. [ AIS ] Key Press the [ AIS ] key to display the AIS (Automatic Identification System) targets information on the display.
  • Page 31 PA Speaker Connection Cable ( Red & Shield ) Connects the GX2000/GX2100 to a optional PA speaker. Refer to section “3 OPTIONS” for a list of optional STANDARD HORIZON Speakers. External Speaker Connection Cable ( White & Shield ) an external speaker. See section “3 OPTIONS” for a list of optional STAN- DARD HORIZON Speakers.
  • Page 32 Microphone The microphone has ClearVoice Noise Reduction Technology which re- duces the amount of background (wind, engine) noise transmitted. Note: Position your mouth about 1/2” away from the microphone hole and speak in a normal voice. Microphone Speaker Audio heard through internal radio speaker is heard through speaker in- side the microphone.

  • Page 33: Basic Operation

    10 BASIC OPERATION 10.1 RECEPTION 1. After the transceiver has been installed, ensure that the power supply and antenna are properly connected. 2. Press and hold the PWR/VOL knob until the radio turns on. 3. Rotate the SQL knob fully counterclockwise. This state is known as “squelch off”.

  • Page 34: Simplex/Duplex Channel Use

    10.4 SIMPLEX/DUPLEX CHANNEL USE Refer to the VHF MARINE CHANNEL CHART (page 121) for instructions on use of simplex and duplex channels. NOTE All channels are factory-programmed in accordance with FCC (USA), Industry Canada (Canada), and International regulations. Mode of op- eration cannot be altered from simplex to duplex or vice-versa.

  • Page 35: Usa, Canada, And International Mode

    10.6 USA, CANADA, AND INTERNATIONAL MODE To change the channel group from USA to Canada or International: 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “CH FUNCTION SETUP”.

  • Page 36: Dual Watch (To Channel16)

    NOTE If the [ CLR ( WX )] key is not pressed the alert will sound for 5 minutes and then the weather report will be received. NOTE While listening to a weather channel, the radio can decode a weather alert and sound an alarm.

  • Page 37: Scanning

    10.9 SCANNING Allows the user to select the scan type from Memory scan or Priority scan. “Memory scan” scans the channels that were programmed into memory. “Pri- ority scan” scans the channels programmed in memory with the priority chan- nel. 10.9.1 Selecting the Scan Type 1.
  • Page 38 10.9.3 Memory Scanning M-SCAN 1. Adjust the SQL knob until background noise disappears. 2. Press the one of the soft key momentarily, then press the [ SCAN ] soft key. “M-SCAN” appears on the display. Scanning will proceed from the lowest to the highest programmed channel number and Preset channel (described in the next chapter) and will stop on a channel when a transmission is re-...

  • Page 39: Preset Channels 0 ~ 9 : Instant Access

    10.10 PRESET CHANNELS 0 ~ 9 : INSTANT ACCESS 10 Preset Channels can be programmed for instant access. Press the one of the soft keys, then press the [ PRESET ] soft key. Pressing the [ PRESET ] key activates the user assigned channel bank. If the [ PRESET ] soft key is pressed and no channels have been assigned, an alert beep will be emitted from the speaker.

  • Page 40: Pa/Fog Operation

    The GX2000/GX2100 has a 30W Hailer built-in and can be used with any 4 Ohm PA Horns. Standard Horizon offers a small and a large PA horn called the 220SW and 240SW. When in Hail mode the PA speaker Listen’s Back (acts as...
  • Page 41 10.11.2 Operating the FOG HORN mode The user can select from “Underway”, “Stop”, “Sail”, “Tow”, “Aground”, “An- chor”, “Horn”, and “Siren”. 1. Press the one of the soft keys momentarily, then press the [ PA/FOG ] soft key. Note: The [ NEXT ] soft key may have to be pressed to see the [ PA/FOG ] soft key if the soft keys have not be customized.

  • Page 42: Fog Signal Timing Chart

    10.11.3 Fog Signal Timing Chart TYPE PATTERN USAGE UNDERWAY One 5-second blasts every 120 seconds. Motor vessel underway and making way. Listen Back 120s STOP Two 5-second blasts (separated by 2 Motor vessel underway but seconds) every 120 seconds. stopped (not making way). Listen Back 120s SAIL...

  • Page 43: Intercom Operation

    10.12 INTERCOM OPERATION To access the following Intercom functions one of the soft keys must be setup as IC. Refer to section “12.12 SOFT KEYS”. In addition an optional RAM3 must be connected to perform intercom func- tions between the radio and the RAM3. 10.12.1 Communication 1.

  • Page 44: Voice Scrambler

    10.13 VOICE SCRAMBLER If privacy of communications is desired, a CVS2500 4 code voice scrambler (VS) can be installed in the transceiver. Contact your Dealer to have a CVS2500 installed. Refer to the section “13.9 SCRAMBLER SETUP” to program the voice scrambler.

  • Page 45: Digital Selective Calling

    11 DIGITAL SELECTIVE CALLING 11.1 GENERAL WARNING This radio is designed to generate a digital maritime distress and safety call to facilitate search and rescue. To be effective as a safety device, this equipment must be used only within communication range of a shore- based VHF marine channel 70 distress and safety watch system.

  • Page 46: Programming The Mmsi

    How can I obtain an MMSI assignment? In the USA, visit the following websites to register: http://www.boatus.com/mmsi/ or http://seatow.com/boating_safety/mmsi.asp In the Canada, visit http://www.ic.gc.ca/epic/site/smt-gst.nsf/en/sf01032e.html or http://www.usps.org/php/mmsi/rules.php 11.2.2 Programming the MMSI WARNING A user MMSI can be inputted only once. Therefore please be careful not to input the incorrect MMSI number.

  • Page 47: Dsc Distress Call

    11.3 DSC DISTRESS CALL The GX2000/GX2100 is capable of transmitting and receiving DSC Distress messages to all DSC radios. The GX2000/GX2100 may be connected to a GPS to also transmit the Latitude, Longitude of the vessel. 11.3.1 Transmitting a DSC Distress Call NOTE To be able to transmit a DSC distress call an MMSI number must be programmed, refer to section “11.2.2 Programming the MMSI.”...
  • Page 48 Transmitting a DSC Distress Alert with Nature of Distress The GX2000/GX2100 is capable of transmitting a DSC Distress Alert with the following “Nature of Distress” categories: Undesignated, Fire, Flooding, Collision, Grounding, Capsizing, Sinking, Adrift, Abandoning, Piracy, MOB 1. Lift the red spring loaded DISTRESS cover and press the [DISTRESS] key.
  • Page 49 2. Press the [ POS/TM ] soft key. 3. Enter the latitude/longitude of your vessel and your local UTC time in the 24-hour notation by the CHAN- NEL knob. Rotate the CHANNEL knob to select the number and press the [ ENT ] soft key to move the cursor to the next character.

  • Page 50: Receiving A Dsc Distress Call

    Pausing a DSC Distress Call After a DSC Distress call is transmitted, the DSC distress call is repeated every 4 minutes until the call is canceled by the user or until the radio is turned on and off again. The GX2000/GX2100 has provision to suspend (Pause) the retransmitting of the distress call by the procedure below.
  • Page 51 to the last selected working channel. 4. Press the [ WPT ] soft key to enter the “Waypoint In- Received DISTRESS Name:VERTEX ID:123456789 put” menu, then enter the desired waypoint name Since: 01:03 -DISTRESS INFO- (up to 11 characters), described previously (select Nature of:Undesignate DIST ID:123456789 the letter/number by rotating the CHANNEL knob...

  • Page 52: All Ships Call

    11.4 ALL SHIPS CALL The All Ships Call function allows contact to be established with DSC equipped vessels without having their MMSI in the individual calling directory. Also, pri- ority for the call can be designated as Urgency or Safety. URGENCY Call: This type of call is used when a vessel may not truly be in distress, but have a potential problem that may lead to a dis- tress situation.

  • Page 53: Receiving An All Ships Call

    11.4.2 Receiving an All Ships Call 1. When an all ships call is received, an emergency alarm will sound. The display shows the MMSI of the vessel trans- mitting the All Ships Call and the radio will change to the requested channel after 10 seconds. 2.

  • Page 54: Individual Call

    11.5 INDIVIDUAL CALL This feature allows the GX2000/GX2100 to contact another vessel with a DSC VHF radio and automatically switch the receiving radio to a desired communi- cations channel. This feature is similar to calling a vessel on CH16 and re- questing to go to another channel (switching to the channel is private between the two stations).

  • Page 55: Setting Up Individual Reply

    desired number and move one space to the right by pressing the [ ENT ] soft key. Repeat this procedure until all nine space of the MMSI number are entered. 11. If a mistake was made entering in the MMSI number repeat pressing the [ BACK ] soft key until the wrong number is selected, then rotate the CHANNEL knob to correct the entry.

  • Page 56: Setting Up Individual/Group Call Ringer

    TO COMPLY” or “UNABLE”. 6. Press the [ ENT ] soft key to store the selected set- ting, then press the [ QUIT ] soft key several times to return to radio operation. 11.5.4 Setting up Individual/Group Call Ringer When a Individual Call or Group Call is received the radio will produce a ring- ing sound for 2 minutes.

  • Page 57: Transmitting An Individual Call

    11.5.5 Transmitting an Individual Call This feature allows the user to contact another vessel with a DSC radio. This feature is similar to calling a vessel on CH16 and requesting to go to another channel. Pre-Programmed Calling 1. Press the [ CALL ( MENU )] key. The “DSC Menu”...
  • Page 58 3. Press the [ SELECT ] soft key. The transceiver will beep, and the “Last Individual Call” will appear. 4. Press the [ NEW ID ] soft key, then select “ ” with the CHANNEL knob. 5. Press the [ SELECT ] soft key. 6.

  • Page 59: Receiving An Individual Call

    11.5.6 Receiving an Individual Call When a Individual DSC call is received, the radio will automatically respond (Default setting) to the calling ship, and switch to the requested channel for voice communications. Refer to section “11.5.2 Setting up Individual Reply” to change the reply to manual if you want to see who is calling before replying to the call.

  • Page 60: Dsc Log Operation

    11.6 DSC LOG OPERATION The GX2000/GX2100 logs received distress calls and individual calls. The DSC Log feature is similar to an answer machine where calls are recorded for review and a “ ” icon will appear on the radios display. The GX2000/GX2100 can store up to the latest 26 Distress, and up to the latest 64 other calls (Indi- vidual, Group, All Ship etc.).

  • Page 61: Reviewing A Logged All Ship Or Individual Call

    11.6.2 Reviewing a Logged All Ship or Individual Call Reviewing a logged All ship or Individual call. 1. Press the [ CALL ( MENU )] key. The “DSC Menu” will appear. 2. Rotate the CHANNEL knob to select “DSC LOG” menu. 3.

  • Page 62: Deleting A Call From The "Dsc Log" Directory

    11.6.3 Deleting a Call from the “DSC LOG” Directory 1. Press the [ CALL ( MENU )] key. The “DSC Menu” will appear. 2. Rotate the CHANNEL knob to select “DSC LOG” menu. 3. Press the [ SELECT ] soft key, then rotate the CHAN- NEL knob to select “LOG DELETE”...

  • Page 63: Group Call

    MMSI numbers. The first digit of a Group MMSI is always set to “0” by International rules. All Standard Horizon radios are preset so when programming a Group MMSI the first digit is set to “0”.

  • Page 64: Transmitting A Group Call

    5. Press the [ SELECT ] soft key. 6. Rotate the CHANNEL knob to scroll through the first letter of the name of the group you want to refer- ence in the directory. 7. Press the [ SELECT ] soft key to store the first letter in the name and step to the next letter to the right.
  • Page 65 5. Press the [ SELECT ] soft key, then rotate the CHANNEL knob to select the operating chan- nel you want to communicate on, then press the [ SELECT ] soft key. If the channel you want is not shown, press the [ MANUAL ] soft key, then rotate the CHANNEL knob to select the operating channel you want to communicate on, then press the [ SELECT ] soft key.

  • Page 66: Receiving A Group Call

    number, repeat pressing the [ BACK ] soft key until the wrong number is selected, then rotate the CHANNEL knob to correct the entry. 9. When finished entering the MMSI number, press and hold the [ SELECT ] soft key. 10.

  • Page 67: Position Request

    Advancements in DSC have made it possible to poll the location of another vessel and show the position of that vessel on the display of the GX2000/ GX2100. Standard Horizon has taken this feature one step further, if any com- patible GPS chart plotter is connected to the GX2000/GX2100, the polled po- sition of the vessel is shown on the display of the GPS chart plotter making it easy to navigate to the location of the polled vessel.

  • Page 68: Setting Up A Position Request Ringer

    11.8.2 Setting up a Position Request Ringer The GX2000/GX2100 has the capability to turn off the Position Request ringer. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “DSC SETUP”...

  • Page 69: Receiving A Position Request

    Manual Request This feature allows you to request the position of vessel by manually entering the MMSI of the ship you want to send your position to. 1. Press the [ CALL ( MENU )] key. The “DSC Menu” will appear. 2.
  • Page 70 Manually reply: 1. When a position request call is received from an- other vessel, the display will be as shown in the il- lustration at the right. 2. A ringing alarm sounds 4 times. To send your ves- sels position to the requesting vessel, press the [ RE- PLY ] soft key.

  • Page 71: Position Report

    11.9 POSITION REPORT The feature is similar to Position Request, however instead of requesting a position of another vessel this function allows you to send your position to another vessel. Your vessel must have an operating GPS receiver connected for the GX2000/GX2100 to send the position. NOTE To transmit a Position Report Call, a GPS must be connected to the radio and the GX2000 / GX2100 Individual directory must be programmed...
  • Page 72 the directory, then press the [ SELECT ] soft key. 5. Press the [ YES ] soft key to send your posi- tion to the selected vessel. 6. Press the [ QUIT ] key to return to radio opera- tion. Manual Calling This feature allows you to send your position to another vessel by manually entering the MMSI of the ship you want to send your position to.

  • Page 73: Receiving A Dsc Position Report Call

    11.9.3 Receiving a DSC Position Report Call When another vessel transmits their vessels location to the GX2000/GX2100 the following will happen: 1. A ringing sound will be produced when the call is received and NMEA sentences DSC, DSE are outputted so the position can be shown on a chart plotter or a computer.
  • Page 74 Saving a Position Report as a Waypoint The GX2000/GX2100 can save a Position Report call in the radios memory as a waypoint. 1. After the Position Report call has been re- ceived: Press the [ SAVE ] soft key. 2. Rotate the CHANNEL knob to change the first letter in the name of the waypoint and press the [ ENT ] soft key.

  • Page 75: Manual Inputting Of The Gps Location Lat/Lon

    11.10 MANUAL INPUTTING OF THE GPS LOCATION LAT/LON You may send the Latitude/Longitude of your vessel manually even if the GX2000/GX2100 is not connected the GPS receiver unit. After the position is entered, transmitting a DSC Distress, Position Request, or Position Report will contain the manually entered position.

  • Page 76: Auto Dsc Polling

    11.11 AUTO DSC POLLING The GX2000/GX2100 has the capability to automatically track four stations programmed into the Indvidual directory. The following procedure allows the time interval between position requests to be setup. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 77: Enable/Disable Auto Dsc Polling

    6. Repeat steps 4 and 5 for CALL 2, CALL 3 and CALL 4 entries. 7. When finished, press the [ QUIT ] soft key numerous times to exit to the radio mode. 11.11.2 Enable/Disable Auto DSC Polling 1. Press the [ CALL ( MENU )] key. The “DSC Menu”...

  • Page 78: Dsc Test

    11.12 DSC TEST This function is used to contact another DSC equipped vessel to ensure the DSC functions of the radio are operating. NOTE To use this feature, the radio you will be transmitting the test call to needs to have the DSC Test feature. To perform the DSC test you will need to enter a MMSI of another vessel into the Individual directory or manually enter in the MMSI using the procedure below.

  • Page 79: Dsc Test Call By Manually Entering Mmsi

    11.12.3 DSC Test Call by Manually Entering MMSI 1. Press the [ CALL ( MENU )] key. The “DSC Menu” will appear. 2. Rotate the CHANNEL knob to select “DSC TEST”, then press the [ SELECT ] soft key. 3. Rotate the CHANNEL knob to select “MANUAL” and press the [ SELECT ] soft key.

  • Page 80: General Setup

    12 GENERAL SETUP The optional CMP30 ( RAM3 ) Remote Station Microphone can also change the SETUP menu using the following procedure. 12.1 DISPLAY The GX2000/GX2100 can select additional screens other than the default normal (Radio) display by using the procedure below. 1.

  • Page 81: Local Distance Receiver Attenuator

    12.2 LOCAL DISTANCE RECEIVER ATTENUATOR In some areas, signals from external sources may cause interference to re- ceiving marine transmissions. The GX2000/GX2100 has two selections, DIS- TANCE - used to receive weak signals (default), and LOCAL - which attenu- ates strong signals that my be interfering with reception. 1.

  • Page 82: Lamp Adjusting

    12.3 LAMP ADJUSTING This menu selection adjusts the backlight intensity. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “GENERAL SETUP” menu. 3. Press the [ SELECT ] soft key, then select “DIMMER” with the CHANNEL knob.

  • Page 83: Time Offset

    12.5 TIME OFFSET Sets the time offset between local time (with inputted offset) and UTC (without time offset) shown on the display. Time is displayed only when an optional GPS Chart Plotter is connected. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 84: Time Area

    12.6 TIME AREA This menu selection allows the radio to show UTC time or local time with the offset. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears, then select “GENERAL SETUP” with the CH knob. 2.

  • Page 85: Unit Of Measure

    12.8 UNIT OF MEASURE Allows Navigation and AIS displays to be shown in “Knot”, “Mile/Hour” or “Kilo- Meter/Hour” (for speed) and “Nautical Mile” or “Kilo-Meter” (for distance). NOTE A GPS must be connected to the radio to be able to show SPEED and DISTANCE.

  • Page 86: Magnetic

    12.9 MAGNETIC This selection allows customizing the GPS COG (Course Over Ground) dis- played in True or Magnetic. NOTE A GPS must be connected to the radio to be able to show COG. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 87: Fog Alert Tone Frequency

    12.11 FOG ALERT TONE FREQUENCY The function allows the radio to be setup to send the proper fog frequency which is dependant on vessel size, shown below: 70 - 200Hz: Vessel that are 200 meters or more in length 130 - 350Hz: Vessel that are 75 Meters but less than 200 meters or more in length 250 - 525Hz: Vessel that are 66 Feet (20 Meters) but less than 247.5 Feet (75 Meters) in length...

  • Page 88: Soft Keys

    12.12 SOFT KEYS This menu item allows selection of the number of soft keys, soft key selection and how long the display will show the soft key icon after a soft key is pressed. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 89: Channel Function Setup

    13 CHANNEL FUNCTION SETUP 13.1 CHANNEL GROUP This section selects a channel group from USA, Canada, and International. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “CH FUNCTION SETUP”.

  • Page 90: Scan Type

    13.3 SCAN TYPE This selection is used to select the scan mode between “Memory Scan” and “Priority Scan”. The default setting is Priority Scan. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2.

  • Page 91: Priority Channel

    13.5 PRIORITY CHANNEL By default the radio priority channel is set to channel 16. This procedure allows the radio to use a different priority channel used when priority scanning. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 92: Channel Name

    13.7 CHANNEL NAME When radio mode (NORMAL) is selected, the display will show a name under the channel number. This name describes the use of the channel. The radio has the capability to customize the name by the procedure below. Example: CH69 PLEASURE to HOOKUP 1.

  • Page 93: Station Name

    13.8 STATION NAME This function allows you to change the name of the radio or second station microphone. Example: “Radio - Cabin”, “RAM1 - Flybridge”. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2.

  • Page 94: Scrambler Setup

    13.9 SCRAMBLER SETUP NOTE Operates only when the optional CVS2500 is installed. This menu will not appear unless a CVS2500 is installed. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “CH FUNCTION SETUP”.

  • Page 95: Demo Mode

    13.10 DEMO MODE This mode is used by Standard Horizon sales persons and dealers to demon- strate radio, DSC and AIS functions. Demo mode allows Latitude, longitude and time to be entered to simulate radio displays. When DEMO mode is en- abled, the radio display will automatically switch from NORMAL, COMPASS, AIS and WAYPOINT displays.

  • Page 96: Dsc Setup

    14 DSC SETUP 14.1 INDIVIDUAL DIRECTORY The GX2000/GX2100 has a DSC directory that allows you to store a vessel or person’s name and the MMSI number associated with vessels you wish to transmit Individual calls, Position Requests and Position Send transmissions. To transmit an Individual call you must program this directory with information of the persons you wish to call, similar to a cellular phones telephone directory.

  • Page 97: Individual Reply

    NEL knob to correct the entry. 12. To store the data entered, press and hold the [ ENT ] soft key. 13. To enter another individual address, repeat steps 5 through 12. 14. Press the [ QUIT ] soft key several times to return to radio operation. 14.2 INDIVIDUAL REPLY This menu item sets up the radio to automatically (default setting) or manually respond to a DSC Individual call requesting you to switch to a working channel...

  • Page 98: Individual Ringer

    MMSI numbers. The first digit of a Group MMSI is always set to “0” by International rules. All Standard Horizon radios are preset so when programming a Group MMSI the first digit is set to “0”.
  • Page 99 another group of vessels may program in the same Group MMSI. If this happens, simply change one or more of the last 5 digits of the Group MMSI. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 100: Position Reply

    14.6 POSITION REPLY The GX2000/GX2100 can be set up to automatically (default setting) or manu- ally send your position when requested by another vessel. This selection is important if you are concerned about someone polling the position of your vessel that you may not want to. In the manual mode you will see the MMSI or persons name shown on the display allowing you to choose to send your posi- tion to the requesting vessel.

  • Page 101: Dsc Beep

    14.7 DSC BEEP This feature allows the alarm beeps to be turned on (default setting) or off when a DSC call is received. The DSC calls that can be customized are: Indi- vidual, Group, All Ships, Position Request, Position Report, Geographic Call using the procedure below: 1.

  • Page 102: Ais/Compass Setup

    15 AIS/COMPASS SETUP 15.1 AUTOMATIC IDENTIFICATION SYSTEM AIS NOTE The MATRIX AIS GX2100 does not require a special marine VHF an- tenna to receive AIS transmissions. The MATRIX AIS GX2100 does not transmit AIS signals, it is NOT recommended to use an antenna dedi- cated for AIS operation.

  • Page 103: Direction

    15.2 DIRECTION This function allows you to select the top of the AIS compass to be orientated in Course Up or North Up. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “AIS/ COMPASS SETUP”.

  • Page 104: Cpa Alarm

    15.4 CPA ALARM This function allows you to set the CPA (Closest Point of Approach) function. : CPA means the positions at which two moving vessels reach their closest possible distance. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu”...

  • Page 105: Display Range

    the TCPA alarm will sound. 6. Press the [ ENT ] soft key, then rotate the CHANNEL knob to set the Alarm item to “On”. 7. Press the [ ENT ] soft key to store the selected setting. 8. Press the [ QUIT ] soft key several times to return to radio operation.

  • Page 106: Ais Operation

    15.7 AIS OPERATION The GX2100 is equipped with an AIS ( A ) receiver UTOMATIC DENTIFICATION YSTEM and can display AIS targets around your vessel on the radios display. There- fore, you can identify and avoid other large vessels nearby your vessel. The GX2000 can also show AIS targets, however a separate AIS receiver or transponder with NMEA VDM 34800 baud must be connected to the acces- sory cable.

  • Page 107: Ais Range

    15.7.1 Transmitting and Individual call to a AIS Ship It is possible for the GX2000 or GX2100 to transmit a DSC Individual call to a received AIS target by the procedure below: 1. Press the one of the soft keys momentarily, then press the [ CALL ] soft key.

  • Page 108: Waypoints

    16 WAYPOINTS The GX2000/GX2100 is capable of storing up to 100 waypoint and navigating to them using the compass page. In addition DSC distress calls with position or a position received from a an- other DSC radio using DSC polling can be navigated to. 16.1 MARKING A POSITION This feature allows the radio to mark the current position of the vessel.

  • Page 109: Adding A Waypoint

    16.2 ADDING A WAYPOINT 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “WAYPOINT SETUP”. 3. Press the [ SELECT ] soft key, then select “WAYPOINT DIRECTORY”...

  • Page 110: Editing A Waypoint

    16.3 EDITING A WAYPOINT This function allows a previously entered waypoint to be edited. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2. Rotate the CHANNEL knob to select “WAYPOINT SETUP”. 3. Press the [ SELECT ] soft key, then select “WAYPOINT DIRECTORY”...

  • Page 111: Saving A Dsc Position Call As A Waypoint

    16.5 SAVING A DSC POSITION CALL AS A WAYPOINT When a position is received from a another DSC radio the GX2000/GX2100 allows the position to be saved as a waypoint. 1. After a position has been received, press the [ SAVE ] soft key two times. 2.

  • Page 112: Stop Navigating To A Waypoint

    16.7 STOP NAVIGATING TO A WAYPOINT To stop navigating to a waypoint, the radio must be switched to Normal Mode with the following procedure. 1. Press and hold down the [ CALL ( MENU )] key until “Setup Menu” appears. 2.
  • Page 113 MEMO GX2000/GX2100 Page 113...

  • Page 114: Cmp30 Ram3 Remote Mic Operation

    17 CMP30 RAM3 REMOTE MIC OPERATION When the Remote MIC is connected to the GX2000/2100, all VHF, DSC, setup menus, AIS, Waypoint, Compass functions and PA/Fog modes can be remotely operated. The CMP30’s operation is same as GX2000/GX2100 except the receiver audio volume setting and squelch level setting.
  • Page 115 PTT (Push-To-Talk) Key Push this key to enable the transmitter. POWER ( ) Key Press and hold down this key to turn the transceiver and Remote MIC on or off. MICROPHONE The internal ClearVoice Noise Canceling mic is located here.. When transmitting, position your mouth about 1/2 to 1 inch (1.2 ~ 2.5 cm) away from the small mic hole.

  • Page 116: Assigning Soft Keys

    [ CLR/WX ] Key Press to CLEAR a function or menu selection. Press and hold to select NOAA Weather channels. Press and hold again to exit Weather mode and revert to radio mode. Secondary use Hold down the [ 16/9 ] key while pressing the [ WX ] key to change the mode from USA to International or Canadian.
  • Page 117 program the other soft keys. 7. Press the [ QUIT ] soft key, then press the [ ] or [ ] key to select “KEY TIMER” (selects how long the soft key icon will be shown on the display after a soft key is pressed, default is 5 seconds).

  • Page 118: Maintenance

    Ensure that the supply voltage to the transceiver does not exceed 16 VDC or fall below 11 VDC. • Use only STANDARD HORIZON-approved accessories and replacement parts. In the unlikely event of serious problems, please contact your Dealer or our repair facility.

  • Page 119: Troubleshooting Chart

    An “RA” Return Authorization number is not necessary to send a product in for service. Include a brief note describing the problem along with your name, return address, phone number, and proof of purchase. 18.3 TROUBLESHOOTING CHART SYMPTOM PROBABLE CAUSE REMEDY Transceiver fails to No DC voltage to the...

  • Page 120: Channel Assignments

    19 CHANNEL ASSIGNMENTS Tables on the following columns list the VHF Marine Channel assignments for U.S.A. and International use. Below are listed some data about the charts. 1. VTS. Where indicated, these channels are part of the U.S. Coast Guard’s Vessel Traffic System.
  • Page 121 VHF MARINE CHANNEL CHART CHANNEL USE D 156.050 160.650 Public Correspondence (Marine Operator) 156.050 Port Operation and Commercial. VTS in selected areas D 156.100 160.700 Public Correspondence (Marine Operator) D 156.150 160.750 Public Correspondence (Marine Operator) 156.150 U.S. Government Only, Coast Guard D 156.200 160.800 Public Correspondence (Marine Operator), Port operation, ship movement 156.200...
  • Page 122 VHF MARINE CHANNEL CHART CHANNEL USE D 156.025 160.625 Public Correspondence (Marine Operator) D 156.075 160.675 Public Correspondence (Marine Operator), Port operation, ship movement 156.075 Public Coast: Coast Guard; East Coast: commercial fishing only D 156.125 160.725 Public Correspondence (Marine Operator), Port operation, ship movement 156.125 Public Coast: Coast Guard;...
  • Page 123 VHF MARINE CHANNEL CHART CHANNEL USE D 157.025 161.625 Port operation, ship movement 157.025 Commercial D 157.075 161.675 Port operation, ship movement 157.075 U.S. Government Only - Environmental protection operations. 157.075 Canadian Coast Guard Only D 157.125 161.725 Public Correspondence (Marine Operator), Port operation, ship movement 157.125 U.S.
  • Page 124 Points of communica- Points of communica- Carrier frequency Carrier frequency tion Intership and be- tion Intership and be- Channel tween coast and ship tween coast and ship designator Ship Coast Ship Coast u n l e s s o t h e r w i s e u n l e s s o t h e r w i s e transmit transmit...
  • Page 125 4: Use of 156.875 MHz is limited to communications with pilots regarding the movement and docking of ships. Normal output power must not exceed 1 watt. 5: 156.375 MHz and 156.650 MHz are available primarily for intership navigational com- munications. These frequencies are available between coast and ship on a secondary basis when used on or in the vicinity of locks or drawbridges.

  • Page 126: Warranty

    Speakers, Antennas, Carrying Accessories, Power Supplies, and Signaling Boards. To receive warranty service, the purchaser must deliver the Product, transpor- tation and insurance prepaid, to STANDARD HORIZON (a division of VER- TEX STANDARD), Attention Marine repairs 10900 Walker Street, Cypress, CA 90630.
  • Page 127 Products on which the serial number has been removed, defaced, or changed. STANDARD HORIZON cannot be responsible in any way for ancillary equip- ment not furnished by STANDARD HORIZON which is attached to or used in connection with STANDARD HORIZON’s Products, or for the operation of the Product with any ancillary equipment, and all such equipment is expressly excluded from this warranty.
  • Page 128 Product Support Inquiries If you have any questions or comments regarding the use of the radio, you can visit the STANDARD HORIZON Web site to send an E-Mail or contact the Product Support team at (714) 827-7600 ext 6300 M-F 7:00- 5:00PST.

  • Page 129: Reset Procedures

    21 RESET PROCEDURES 21.1 MEMORY CLEAR To clear the Scan memory and Preset memory: 1. Turn the radio off. 2. Press and hold in the three [ Programmable ] keys while turning the radio 21.2 MICROPROCESSOR RESETTING To clear all memories and other settings to factory defaults (except the Chan- nel Group, MMSI number, and DSC directory information): 1.

  • Page 130: Specifications

    22 SPECIFICATIONS Performance specifications are nominal, unless otherwise indicated, and are subject to change without notice. 22.1 GENERAL Channels ..........All USA, International and Canadian Input Voltage ............... 13.8 V DC ±20% Current Drain Standby ..........0.55 A (GX2100), 0.45 A (GX2000) Receiver (at Maximum AF Output) ..
  • Page 131 22.3 RECEIVER (for Voice and DSC) Frequency Range ..........156.050 MHz to 163.275 MHz Sensitivity 20 dB Quieting ................0.35 µV 12 dB SINAD ................. 0.30 µV Squelch Sensitivity (Threshold) ............. 0.13 µV Modulation Acceptance Bandwidth ...........±7.5 kHz Selectivity (Typical) Spurious and Image Rejection ....
  • Page 132 22.6 DIMENSIONS 6.3” ( 159 mm ) 6.2” ( 156 mm ) 7.1” ( 180 mm ) 4.8” ( 121.8 mm ) 1.5” ( 38.6 mm ) 3.8” ( 97.4 mm ) 7.1” ( 180 mm ) 1” ( 25.1 mm ) 1.6”...
  • Page 133 MEMO GX2000/GX2100 Page 133...
  • Page 134 MEMO Page 134 GX2000/GX2100...
  • Page 135 This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device does not cause harmful interference. Part 15.21: Changes or modifications to this device not expressly ap- proved by Vertex Standard could void the User’s authorization to oper- ate this device.
  • Page 136 Copyright 2010 VERTEX STANDARD CO., LTD. Marine Division of VERTEX STANDARD All rights reserved. US Headquarters No portion of this manual 10900 Walker Street, Cypress, CA 90630, U.S.A. may be reproduced www.standardhorizon.com without the permission of VERTEX STANDARD CO., LTD. Page 136 GX2000/GX2100...

This manual is also suitable for:

Matrix gx2000

Table of Contents

Save PDF
