Audio settings

The Audio settings menu allows to configure the audio output.
PARAMETER
Out mode
Pilot tone
Balance
Mix Mode
Pwr limit
Vol. boost
Equalizer
9
SETTING MEANING
The left and right signals are available as usual. The
Stereo Balance setting serves to adjust the balance between
the left and right stereo signal.
The left-right signals are mixed and are available as a
mono signal in both headphone channels.
Mix
The Mix mode setting serves to adjust the relative levels
of the two separate channels in the mixer mono signal.
When the Pilot tone is enabled, the audio output is
muted unless the correct carrier is detected. Pilot tone
Yes allows working with lower RF squelch, increasing the
coverage and the robustness especially in presence of
digital television carriers (DVB-T).
When the Pilot tone is disable, the audio output is
No
muted if RF level < Squelch level
For the presence/absence of audio output, check the upper symbol in the
status display
When Out
This menu allows to adjust the balance between the left
mode set to
and right stereo signal in 35 steps.
Stereo
Push UP/DOWN button to change the balance.
When Out This menu allows to adjust the relative levels of the two
mode set to
separate channels in the mixer mono signal in 35 steps.
Mix
Push UP/DOWN button to change the level.
OFF This menu allows to limit the power output. Set the
32Ω100mW proper impedance@power according to the earphones
32Ω50mW used.
32Ω30mW NOTE: if set to OFF, there is no power limit control.
16Ω100mW
16Ω50mW
This menu allows to increase the volume of the output
headphones, selectable in 3 dB steps from 0 dB to 12
0/3/6/9/12dB
dB. Set the appropriate volume boost and then adjust
the volume with the control knob.
This menu allows to equalizer Low and High frequencies
of the audio (2dB steps from -12dB to 12dB )
-12dB/+12dB
1. Push UP/DOWN button to increase/decrease
the gain of the Low frequencies (50Hz)
2. Push SEL button to shift on High frequencies,
3. Push UP/DOWN button to increase/decrease
the gain of the High frequencies (10kHz)
4. Keep push SEL button to SAVE
