WisyCom MPR30-IEM User Manual page 12

Arrow mode
This menu allows to set the quick menu. The quick menu is displayed pushing UP or DOWN
button when the receiver is on the
Bal/Mix enters directly to
Audio settings>Balance/Mix mode menu (according to the Out mode configured).
CH enters directly to
1)
or
2)
Push SEL button to change the quick menu between the 2 menus.
NOTE: the receiver remember the last quick menu used, therefore when the user
enter again on the quick menu, it enters directly to the latest quick menu used.
Display
This menu allows to configure display setting
PARAMETER
LED
Contrast
Low timeout
(sec)
Off timeout (sec)
Infrared menu
By this menu, MPR30-IEM can be connected to IRDA for setup or firmware upgrades.
When the Infrared interface is active, the following screen is displayed.
NOTE: while in this menu display is not automatically turned off.
11
Status
Edit RX>Gr-Ch menu, to change channel
Audio settings>Balance/Mix mode menu (according to the Out mode
configured).
SETTING MEANING
Full 3 LED setting are available:
Alarm Full: LED indicators works normally
OFF Alarm: LED indicators lights up only when an alarm
happened
OFF: LED indicators remain off
0÷5
Change contrast display from 0 (min) to 5 (max).
5÷60
(5sec. steps)
Low timeout sets the timeout from 5 to 60 seconds
(5sec steps) to decrease the brightness display.
10÷120
Off timeout sets the timeout from 10 to 120 seconds in
(10sec. steps)
10 sec. steps to turn off the display. With OFF setting
/ OFF
the display never turns off.
display.
