Audio settings

The Audio settings menu allows to configure the audio output.
PARAMETER SETTING
Stereo
Mono
Out mode
Mix
Equalizer
Vol. boost
-12/-6/0/3/6/9/12dB
16Ω/32Ω
Output load
OFF
Pwr limit
battery) /
50mW
10
From Status Display push SEL and EXIT together to enter on the
Main menu
Use UP/DOWN to navigate on all available menus
Push SEL to select a menu item
Use UP/DOWN to move on the different parameters of the menu
Push SEL to modify the parameter menu
Use UP/DOWN to change the parameter value
Keep push SEL to save changing
Push EXIT to return on the Main Menu
Push EXIT to return on the Status display
Low and High
frequencies
-12dB/+12dB
1dB steps
(only using lithium
100mW /
30mW
/
NOTE: When the volume knob is rotated, appears a screen with a
volume bar and the values of Pwr limit, Outpul load and Vol. boost
MPR50-IEM User Manual
MEANING
The left and right signals are available as usual. The Balance
setting serves to adjust the balance between the left and
right stereo signal.
The left-right signals are mixed and are available as a mono
signal in both headphone channels. It is not possible to
adjust the level of the 2 channels as in Out mode Mix.
The left-right signals are mixed and are available as a mono
signal in both headphone channels.
The Mix mode setting serves to adjust the relative levels of
the two separate channels in the mixer mono signal.
This menu allows to of adjusting the gain of low and high
frequency components (bass and treble) within the audio
signal.
1. Push UP/DOWN button to increase/decrease the
gain of the Low frequencies (50Hz)
2. Push SEL button to shift on High frequencies,
3. Push UP/DOWN button to increase/decrease the
gain of the High frequencies (10kHz)
4. Keep push SEL button to SAVE
This menu allows to increase or decrease the volume of the
output headphones, selectable from -12 dB to 12 dB. Set the
appropriate volume boost and then adjust the volume with
the control knob.
Set the Output load according to the impendence of the
headphones connected
This menu allows to limit the power output. If set to
OFF(only lithium battery), there is no power limit control. If
set to OFF using alkaline or NiMH batteries, the receiver set
automatically the max value permitted (100mW)
