Note
If you are using a SnapGear unit model SG560, SG565 or SG580, you may want to skip
to information on establishing multiple broadband connetions. This information is in the
section entitled Port Based VLANs on page 97.
Once the Internet connections have been configured, specify the conditions under which
the Internet connections are established.

Internet Failover

Note
If you have configured your SG560, SG565 or SG580's switch as separate ports, and are
establishing multiple PPPoE ADSL Internet connections using two or more of these ports,
it is important that each port is connected to a remote device with a unique MAC address.
This is almost definitely the case if each of the Internet connections are through different
ISPs, otherwise you may have to request this specifically from your ISP.
If this is not possible, set each of the ADSL modems to routing or NAT rather than
bridged mode. Typically this means the ADSL modem terminates the PPPoE
connection, and the SG appliance is configured with DHCP or manually assigned
settings, using the ADSL modem as a gateway.
SnapGear units support three connection levels. A connection level consists of one or
more Internet connections. When all primary connections are functioning as expected,
the primary connection level is deemed to be up.
If one or more of the primary connections should fail, the SnapGear unit drops back to
the secondary connection level. This typically involves bringing up a secondary Internet
connection, until the primary Internet connection or connections become available again.
You may also optionally configure the tertiary failover level. If one or more of the
secondary connections should fail, the SnapGear unit drops back to the tertiary
connection level. This is typically a "last resort" dialup link to the Internet, but may be any
kind of network connection. The primary connection level and secondary connection
level are tested in turn, until one becomes available.
