Secure Computing SG300 User Manual page 37

Ensure all PCs on the network are set up to automatically obtain network configuration as
per Automatic configuration of your LAN, then restart them.
Note
The purpose of restarting the computers is to force them to update their automatically
configured network settings. Alternatively you can use a utility such as ipconfig to
release then renew the DHCP lease, or disable and re-enable the network connection.
Manual configuration of your LAN
Click Start > (Settings >) Control Panel and double-click Network Connections (or in
95/98/Me, double-click Network).
If presented with multiple connections, right-click Local Area Connection (or appropriate
network connection) and select Properties.
Select Internet Protocol (TCP/IP) and click Properties (or in 95/98/Me, TCP/IP > [your
network card name] if there are multiple entries).
Enter the following details:
IP address is an IP address that is part of the same subnet range as the SnapGear
unit's LAN connection (e.g. if using the default settings, 192.168.0.2 –
192.168.0.254).
Subnet mask is the subnet mask of the SnapGear unit's LAN connection (if using the
default settings, 255.255.255.0).
Default gateway is the IP address of the SnapGear unit's LAN connection (if using
the default settings, 192.168.0.1).
Preferred DNS server is the IP address of the SnapGear unit's LAN connection (if
using the default settings, 192.168.0.1).
Click OK (or in 95/98/Me, Add then OK, reboot the PC if prompted to do so).
Perform these steps for each PC on your network.
Getting Started
31
