Other Functions - Icom MR-1000RII Instruction Manual

D Antenna rotation speed
• MR-1000RII: [CHN], [CHN-01], [EXP], [EXP-01]
• MR-1000TII, MR-1000TIII
The antenna rotation speed can be selected between
48 rpm and 36 rpm. (Default: 48 rpm)
Hold down [–]/[ ] for 1 second to select 36 rpm,
hold down [+]/[ ] for 1 second to select 48 rpm.
• MR-1000RII: [CHN-02], [EXP-02]
The antenna rotation speed can be selected between
36 rpm and 24 rpm. (Default: 36 rpm)
Hold down [–]/[ ] for 1 second to select 24 rpm,
hold down [+]/[ ] for 1 second to select 36 rpm.
D Test pattern indication
To check the CRT display distortion, a test pattern can
bee displayed.
While holding down [MENU]/[
to display the test pattern.
To return to normal operating mode, turn OFF the
power, then turn it ON again.
D Simulator screen
The MR-1000RII/TII/TIII has simulator screen capabil-
ity.
q While holding down [BRILL]/[
[ ] to turn ON the power.
w After the count down ends, the standby screen ap-
pears.
e Push [TX (SAVE)]/[
tor screen.
r To return to normal operating condition, turn OFF
the power, then ON again.
D All reset
q While holding down [TARGET]/[
(VRM1)]/[
[ ], turn ON the power.
w Follow the guidance.
], turn ON the power
], push [POWER]/
] to display the simula-
], [EBL1
] and [EBL2 (VRM2)]/

OTHER FUNCTIONS

9
30
