13
SPECIFICATIONS
D Scanner unit
◆ EX-2714 (Radome)
• Type
• Rotation speed (typical)
• Beam width (typical)
• Side lobe (typical)
[CHN], [CHN-01], [EXP], [EXP-01]
[CHN-02], [EXP-02]
• Polarization
• Transmission frequency
• Peak output power
• Pulse width
[CHN], [CHN-01], [EXP], [EXP-01]
[CHN-02], [EXP-02]
• Mixer and Local Oscillator
• Transmitting Tube
• Modulator
• Duplexer
• Tuning system
• Intermediate frequency
• IF Band width
• Dimensions
[CHN], [CHN-01], [EXP], [EXP-01]
[CHN-02], [EXP-02]
• Usable temperature range
• Relative Humidity
• Weight
◆ EX-2780 (Open array)
• Type
• Rotation speed (typical)
• Beam width (typical)
• Side lobe (typical)
• Polarization
• Transmission frequency
• Peak output power
• Pulse width
• Mixer and Local Oscillator
• Transmitting Tube
• Modulator
• Duplexer
• Tuning system
• Intermediate frequency
• IF Band width
• Diameter of rotation/height
• Usable temperature range
• Relative Humidity
• Weight
All stated specifications are subject to change without notice or obligation.
37
: 2 feet Slotted Waveguide Array, enclosed in a radome.
: 24 rpm, 36 rpm, 48 rpm*
*only [CHN], [CHN-01], [EXP], [EXP-01]
: Horizontal beam
Vertical beam
22˚
:
–18 dB
–22 dB
: Horizontal
: 9410 MHz
30 MHz P0N
±
: 4 kW
:
80 ns/2880 Hz, 80 ns/2160 Hz, 250 ns/2160 Hz,
350 ns/2160 Hz, 900 ns/720 Hz
80 ns/2160 Hz, 80 ns/1440 Hz, 250 ns/1440 Hz,
350 ns/1440 Hz, 350 ns/720 Hz, 900 ns/720 Hz
: Microwave Integrated Circuit
: Magnetron
MAF1421B
: FET switching
: Circulator
: Automatic/manual selectable
: 60 MHz
: 10 MHz, 3 MHz
:
607 (Ø)×243 (H) mm; 23.9 (Ø)×9.6 (H) in
640 (W)×256 (H)×640 (D) mm,
25.2 (W)×10.1 (H)×25.2 (D) in
: –25˚C to +70˚C; –13˚F to 158˚F
: Less than 95% at 40˚C (+104˚F)
: Approximately 8 kg; 17.6 lb (without cable)
: 120 cm Slotted Waveguide Array
: 22 rpm
(only MR-1000TIII)
: Horizontal beam
Vertical beam
25˚
: –24 dB
: Horizontal
: 9410 MHz
30 MHz P0N
±
: 4 kW
, 6 kW
(MR-1000TII)
: 80 ns/2880Hz, 80 ns/2160 Hz, 250 ns/2160 Hz,
350 ns/2160 Hz, 900 ns/720 Hz, 900 ns/660 Hz*
: Microwave Integrated Circuit
: Magnetron
MAF1421B
MAF1422B
: FET switching
: Circulator
: Automatic/manual selectable
: 60 MHz
: 10 MHz, 3 MHz
: 1205/381 mm; 47.4/15 in
: –25˚C to +70˚C; –13˚F to 158˚F
: Less than 95% at 40˚C (+104˚F)
: Approximately 17 kg; 37.5 lb (without cable)
, 24 rpm, 36 rpm, 48 rpm
(MR-1000TIII)
*only
MR-1000TIII
(MR-1000TII)
(MR-1000TIII)
