  • Page 1 Powerware 9315 UPS ® 300–500 kVA Operation Manual...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions that you should follow during installation and maintenance of the UPS and batteries. Please read all instructions before operating the equipment and save this manual for future reference. Consignes de sécurité CONSIGNES DE SÉCURITÉ...

  • Page 3: Table Of Contents

    2−1 Typical Powerware 9315 UPS System .........
  • Page 4 ............7−7 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com EATON Powerware ®...
  • Page 5 ............9−3 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com EATON Powerware ®...
  • Page 6 ............. . W−1 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com EATON Powerware ®...
  • Page 7 ............5−1 Figure 5-2. Parts of the LCD Screen (Typical for Powerware 9315 500 480/480V Unit) ..
  • Page 8 Table of Contents This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com EATON Powerware ®...

  • Page 9: Using The Load Off Button

    Congratulations on your purchase of a Powerware 9315 uninterruptible power supply ® (UPS)! The Powerware 9315 online power protection can be used to prevent loss of valuable electronic information, minimize equipment downtime, and/or minimize the adverse effect on equipment production due to unexpected power problems.

  • Page 10: For More Information

    Introduction 1.2 For More Information Refer to the Powerware 9315 (300–500 kVA) UPS Installation Manual for the following additional information: How to prepare your site and plan for installation Detailed step-by-step procedures for installing each component of your system Detailed illustrations of cabinets and optional accessories, including dimensions and connection points.

  • Page 11: Safety Warnings

    Never dispose of batteries in a fire. Batteries may explode when exposed to flame. Keep the UPS doors closed to ensure proper cooling airflow and to protect personnel from dangerous voltages inside the unit. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−1 EATON Powerware ®...

  • Page 12: Typical Powerware 9315 Ups System

    UPS switches, controls, or optional components. 2.3 Looking Inside the UPS The Powerware 9315 is a continuous duty, solid-state UPS that supports the following equipment: process control, data processing, telecommunications/PBX, research, and medical. The Powerware 9315 maintains power to the critical loads during commercial electrical power brownout, blackout, overvoltage, undervoltage, and out-of-tolerance frequency conditions.

  • Page 13: Product Specifications

    The operation of the UPS system is described in greater detail in Chapter 3, Understanding UPS Operation." Chapter 10, Product Specifications," outlines the storage and operating specifications for the UPS and optional battery. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−3 EATON Powerware ®...

  • Page 14: Ups Standard Features

    The filter also reduces input harmonic current distortion and minimizes upstream interference that can damage sensitive hardware components. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−4 EATON Powerware ®...

  • Page 15: Emergency Load Off

    Several battery capacities are available. The UPS battery cabinets can be paralleled; you can increase your battery backup time by adding battery cabinets to your UPS system. The Powerware 9315 can support up to four battery cabinets. 2.5.2 External Battery Disconnect An optional DC circuit breaker, enclosed in a wall-mounted box adjacent to the UPS, provides a manual means of disconnecting a battery that is located remotely from the UPS.

  • Page 16: Upgrade Capability

    An optional modem is available for use with the UPS Remote Notification feature described in Chapter 8, Remote Notification." Refer to the manual supplied with the modem for operating instructions. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−6 EATON Powerware ®...

  • Page 17: Customer Convenience Outlet

    This symbol indicates that you should not discard the UPS or the UPS batteries in the trash. The UPS may contain sealed, lead-acid batteries. Batteries must be recycled. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−7 EATON Powerware ®...
  • Page 18 Getting Started This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 2−8 EATON Powerware ®...

  • Page 19: Normal Mode

    Normal" appears in the status area of the LCD screen. Figure 3-1 shows the path of electrical power through the UPS system when the UPS is operating in Normal mode. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−1 EATON Powerware ®...

  • Page 20: Figure 3-1. Path Of Current Through The Ups In Normal Mode

    If the UPS suffers an internal failure, it switches automatically to Bypass mode and remains in that mode until the failure is corrected and the UPS is back in service. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−2 EATON Powerware ®...

  • Page 21: Bypass Mode

    Bypass mode is a normal operating mode, and not an alarm condition. However, if the UPS is unable to return to Normal mode following an automatic transfer to Bypass mode, an alarm condition is recorded. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−3 EATON Powerware ®...

  • Page 22: Battery Mode

    Normal mode and alarm indications clear. However, the process of returning to Normal mode is not instantaneous. The rectifier gradually draws increasing power from the incoming utility until Normal mode is achieved. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−4 EATON Powerware ®...

  • Page 23: Monitoring And Controlling Ups Operation

    These control power to and from the UPS, and allow you to change the UPS mode manually. The Control Panel is discussed in Using the Control Panel" on page 4−1. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−5 EATON Powerware ®...
  • Page 24 Understanding UPS Operation This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 3−6 EATON Powerware ®...

  • Page 25: Starting And Stopping The Ups

    C A U T I O N Incorrect use of the power controls on the Control Panel can cause a loss of power to your equipment. Figure 4-1. UPS Control Panel 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 4−1 EATON Powerware ®...

  • Page 26: Resetting The Ups System After Load Off

    The rectifier turns on, then the inverter turns on. The UPS display and alarm alert you to close the battery breaker. 7. Close battery breaker(s). 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 4−2 EATON Powerware ®...

  • Page 27: To Shut Down The Ups From Normal Mode

    To perform maintenance or service on your critical load, you must shut it down first: 1. Turn off all equipment that is being powered through the UPS. 2. Press the LOAD OFF button on the Monitor Panel. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 4−3 EATON Powerware ®...
  • Page 28 Starting and Stopping the UPS This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 4−4 EATON Powerware ®...

  • Page 29: Figure 5-1. Ups Monitor Panel

    (4). A quick reference label describing how to use the Monitor Panel is located inside the UPS above the Control Panel. The following sections describe the Monitor Panel in detail. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−1 EATON Powerware ®...

  • Page 30: Figure 5-2. Parts Of The Lcd Screen (Typical For Powerware 9315 500 480/480V Unit)

    Meters Events Statistics Graphics Setup Figure 5-2. Parts of the LCD Screen (Typical for Powerware 9315 500 480/480V Unit) The UPS status area contains three lines that display the current state of the UPS. The first line shows the present operational mode of the UPS. The second line shows the highest level of the current active alarms, and the third line shows any notices the UPS has posted.

  • Page 31: Using The Monitor Panel 5−1

    All power to the critical load is lost when you press the LOAD OFF button. You should use the LOAD OFF button only when you want to de-energize the critical load. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−3 EATON Powerware ®...

  • Page 32: Reading The Status Indicators

    If any indicator does not illuminate, its LED may need to be replaced. Contact your service representative if you have a problem with the indicator lamps. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−4 EATON Powerware ®...

  • Page 33: Using The Menu Options

    Meters Events Statistics Graphics Setup Figure 5-3. System Meters Screen (Typical for Powerware 9315 500 480/480V Unit) The Input area shows the phase-to-phase voltage, frequency, and phase current of the incoming utility, followed by the kVA, KW, and power factor measurements. The output area shows the same information for the power being output by the UPS.

  • Page 34: Figure 5-4. Load Amps Meters Screen

    Percent 125% 100% 100% Meters System Load Amps Phase A Phase B Phase C Meters Events Statistics Graphics Setup Figure 5-4. Load Amps Meters Screen 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−6 EATON Powerware ®...

  • Page 35: Figure 5-5. Event History Log Screen

    When the scroll bar is in the menu box, the return arrow is in the information area. When the scroll bar is in the information area, you can press the buttons to scroll through the Event History log. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−7 EATON Powerware ®...

  • Page 36: Figure 5-6. Active System Events Screen

    Input power unavailable 001.3 NOTICE: Bypass Not Available ALARM: Shutdown Imminent Events History Active Meters Events Statistics Graphics Setup Figure 5-6. Active System Events Screen 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−8 EATON Powerware ®...

  • Page 37: Figure 5-7. Unit Statistics Screen

    UPS was on bypass, battery, or generator, and the amount of time the UPS logic has been functioning since the start date. The lower right column shows the percent of availability of the UPS and the bypass source. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−9 EATON Powerware ®...

  • Page 38: Figure 5-8. Mimic Screen

    Setup Figure 5-8. Mimic Screen The Mimic screen shows the internal components of the UPS cabinet. The flow of current through the components is highlighted. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−10 EATON Powerware ®...

  • Page 39: Figure 5-9. Time Setup Screen

    To decrease the setting (make it a lower value), press the button. If you want to save the settings upon exit from this screen, be sure the SAVE field is set to YES. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−11 EATON Powerware ®...

  • Page 40: Figure 5-10. Port Setup Screen

    SAVE field is set to YES. The setup screens for Port 1 and Port 2 are identical. For detailed information about configuring the serial ports, see Chapter 7, Serial Communication." 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 5−12 EATON Powerware ®...

  • Page 41: Using Features And Options

    Alarm 2, Building Alarm 3, etc., on the LCD screen of the Monitor Panel. You should use twisted−pair wires for each alarm input and common. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−1 EATON Powerware ®...

  • Page 42: Summary Alarm Contacts

    C A U T I O N Contacts should not be operated in excess of 30 Vac or 42.4V peak AC or DC @ 1A maximum. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−2 EATON Powerware ®...

  • Page 43: Remote Monitor Panel

    (RMPs, Relay Interface Modules (RIMs), or Supervisory Contact Modules) can be installed. See Table 6-1 for the number of accessories permitted. Figure 6-3 shows an RMP. Figure 6-3. Remote Monitor Panel 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−3 EATON Powerware ®...
  • Page 44 The UPS is preparing to shut down because the UPS is in Battery mode and the DC voltage is approaching its low limit. This indicator is accompanied by a horn. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−4 EATON Powerware ®...

  • Page 45: Battery Cabinets

    Several battery capacities are available. The UPS battery cabinets can be paralleled. With this capability, you can increase your battery backup time by adding battery cabinets to your UPS system. The Powerware 9315 can support up to four battery cabinets.

  • Page 46: Relay Interface Module

    UTILITY FAILURE Pins 6 and 15 Contacts are closed when Utility Failure is detected. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−6 EATON Powerware ®...

  • Page 47: Figure 6-5. Supervisory Contact Module

    TB2-19 through TB2-21 SHUTDOWN IMMINENT TB2-22 through TB2-24 Refer to the Supervisory Contact Module section in the Powerware 9315 (300–500 kVA) UPS Installation Manual for TB2 contact configurations. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−7 EATON Powerware ®...
  • Page 48 Using Features and Options This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 6−8 EATON Powerware ®...

  • Page 49: Serial Communication

    DB−25 is disabled for other uses. If you need the DB−25 for an external modem kit, contact your service representative for an internal wiring change. Figure 7-1 shows the location of these items inside the UPS. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−1 EATON Powerware ®...

  • Page 50: Slot Cards

    PORT 2 (DB−25F) RS−232 Connection (disabled by default) Figure 7-1. Location of Communication Bays on the UPS (Powerware 9315 500) 7.2 X−Slot Cards The Powerware 9315 is factory−installed with an X−Slot communication bay, and is compatible with the following cards: Modbus Card −...

  • Page 51: Connecting Equipment To A Serial Port

    Comments +24V +24 Volts DC Transmit Data Input to UPS Receive Data Output from UPS Return 485+ RS-485 + Data 485– RS-485 – Data Return 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−3 EATON Powerware ®...

  • Page 52: Figure 7-4. Port 2 (Db−25) Pin Assignments

    Input to UPS - typically not used by UPS –12V –12 Volts Output from UPS - always true NOTE Pins 5 and 6 are tied together internally. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−4 EATON Powerware ®...

  • Page 53: Configuring The Serial Ports

    To scroll through the available options for that setting, press the button. To save the settings upon exit from this screen, be sure the Save field is set to YES. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−5 EATON Powerware ®...

  • Page 54: Rate

    300 baud is not recommended for any mode except Remote Monitor. You can select a baud rate of 300, 1200, 2400, 4800, 9600, or 19,200. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−6 EATON Powerware ®...

  • Page 55: Data/Stop

    8/1 Handshaking Disabled Each communication port on the UPS operates in one of five modes which you select when configuring the port using the Setup Port screen. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−7 EATON Powerware ®...

  • Page 56: Terminal Mode

    [Ctrl]+[A] Prints all system information [Ctrl]+[B] Prints Battery Test Log To use a key combination, hold down the Control key and press the letter key. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−8 EATON Powerware ®...

  • Page 57: Entire Log (Ctrl + P)

    Inverter Contactor (3) Closed 16:43:15.8 STATUS: Bypass Contactor (K4) Open 16:43:42.4 STATUS: Inverter Normal 16:44:29.1 4001 JUN 04 12:16:35.9 NOTICE: Room High Temperature Figure 7-6. Event History Log 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−9 EATON Powerware ®...

  • Page 58: Meters Printout (Ctrl + M)

    03 NOV 1997 14:22:45 Alarm: None Notice: None Input Output VBC VCA FREQ FREQ 480 480 60.0 60.0 0.95 0.80 Bypass Battery Figure 7-7. System Meters 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−10 EATON Powerware ®...

  • Page 59: System Information Printout (Ctrl + A)

    Event History Log reports either Battery Test Failed, Battery Test Aborted (Load), or Battery Test Aborted (Utility). If the test ran to completion, Battery Passed Test appears in the UPS Event History Log. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−11 EATON Powerware ®...

  • Page 60: System Configuration

    If 1 is entered at the prompt, you can program the building alarm functions: Program Building Alarms 1. Enable/Disable Default Functions 2. Customize Alarm Messages 3. Return to Main Menu Enter Selection: 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−12 EATON Powerware ®...

  • Page 61: Enable/Disable Default Functions

    The line following the Enabled Building Alarm Number(s) label indicates which building alarms are currently enabled. (In this example, Building Alarms 1 and 4 are enabled.) 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−13 EATON Powerware ®...

  • Page 62: Customize Alarm Messages

    If an E is entered at the prompt, the custom messages are used for the building alarm. If a D is entered, the default messages are used for the building alarm. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−14 EATON Powerware ®...

  • Page 63: Program Unit Name

    NOTE Password must be six characters in length. <CR> to return with no change. The password changes if the user enters and verifies the password. The entry must be six characters. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−15 EATON Powerware ®...

  • Page 64: Battery Test Setup

    No Battery Test Scheduled Enter <CR> to return to Battery Test Setup Menu NOTE The unit only performs one battery test in any 24−hour period. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−16 EATON Powerware ®...

  • Page 65: Modify Low Battery Time

    For a list of products available, contact your sales representative. 7.9 Remote Monitor Mode This mode provides the interface for the RMP, RIM, or SCM described earlier. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−17 EATON Powerware ®...
  • Page 66 Serial Communication This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 7−18 EATON Powerware ®...

  • Page 67: Remote Notificaton

    Remote and local ability to clear Call Out alarms and events. Error detection and correction for misconfigured and disconnected modems. Uses standard modems and cables available at your local computer supply center. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−1 EATON Powerware ®...

  • Page 68: Description Of Operation

    The Reset Call Out Alarms command causes the UPS to cease Call Out attempts on a currently active alarm and resets that alarm call. See the following section, Call Out" for more information. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−2 EATON Powerware ®...

  • Page 69: Call Out

    UPS and sending the reset command (press and hold [CTRL] and press [R]) or by turning the key switch on the front of the UPS. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−3 EATON Powerware ®...

  • Page 70: Housekeeping

    An alternative to purchasing a cable is to build your own serial cable using the following pin out description: Male DB-25 Male DB-25 Pin 7 Pin 7 Pin 2 Pin 2 Pin 3 Pin 2 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−4 EATON Powerware ®...

  • Page 71: Configuring The Modem

    [xxxxxxx], then press [ENTER]. 5. To program a group two number, key in [A], [T], [&], [Z], [1], [=], [T], [,], [xxxxxxx], then press [ENTER]. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−5 EATON Powerware ®...

  • Page 72: Configuring The Modem To Call A Numeric

    1. Connect the modem to the PC through the serial port as described in the modem manufacturer’s manual. 2. Key in [A], [T], then press [ENTER]. 3. Confirm that the modem responds with OK" or 0" (zero). 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−6 EATON Powerware ®...
  • Page 73 NOTE To set up a group one or group two number to call a computer, see Configuring the Modem to Call a Remote Computer" on page 8−5. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−7 EATON Powerware ®...

  • Page 74: Configuring The Modem To Answer Incoming Calls

    11. Confirm that the modem responds with OK" or 0" (zero). 12. Key in [A], [T], [&], [Y], [0] (zero), then press [ENTER]. 13. Confirm that the modem responds with OK" or 0" (zero). 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−8 EATON Powerware ®...

  • Page 75: Ups Setup Configuration

    Communication"). If using a standard serial cable, a null modem adapter is required for the connection to the modem. The Powerware 9315 UPS can only use serial Port 2, DB−25F, for the Remote Notification option. This connection is located in the serial communication panel at the base of the UPS cabinet, behind the front door.

  • Page 76: User-Selected Events

    Phase C Current Limit Battery Contactor (K2) Failed Phase C Current Limit Bypass Control Failed Bypass Phase Rotation Go To Bypass Active Battery Ground Fault 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−10 EATON Powerware ®...
  • Page 77 Input Under Frequency Input/Battery Current Limit Logic Power Failed Power Supply Over Voltage Power Supply Under Voltage Rectifier 1.12 Reduced Input Current Limit Testing Battery 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−11 EATON Powerware ®...
  • Page 78 Power Off Switch Rectifier Network Down Testing Battery Three Wire AC Over Voltage Three Wire AC Under Voltage Three Wire Over Freq. Three Wire Under Freq. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 8−12 EATON Powerware ®...

  • Page 79: Maintaining The Ups System

    If the battery cabinet requiring service was not provided by the UPS manufacturer, refer to the battery cabinet manufacturer’s operating manual for instructions on battery cabinet installation and maintenance, or contact your service representative. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 9−1 EATON Powerware ®...

  • Page 80: Performing Preventive Maintenance

    Check the air filters (located behind the front doors) and replace them as necessary. The filter size is 16″ 20″ 1″ Record the results of your checks and any corrective actions in a suitable log. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 9−2 EATON Powerware ®...

  • Page 81: Maintenance Training

    For more information about training and other services, contact Powerware In the United States 1-800-843-9433 In Canada 1-800-461-9166 All other countries Call your service representative 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 9−3 EATON Powerware ®...
  • Page 82 Maintaining the UPS System This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 9−4 EATON Powerware ®...
  • Page 83 The UPS systems are available in 50/60 Hz with various output power ratings. Smaller models within a system may be upgraded in the field to larger models: Table 10-1. Model Numbers System Models Notes Powerware 9315 500 500 kVA 60 Hz only Powerware 9315 500 400 kVA 60 Hz only...
  • Page 84 Electrostatic Discharge (ESD) Meets IEC 801-2 specifications. Withstands up to 25 kV without damage and Immunity with no disturbance or adverse effect to the critical load. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 10−2 EATON Powerware ®...
  • Page 85 Table 10-5. Battery Specifications Battery Type Sealed, maintenance-free, high rate discharge, lead-acid cells Nominal Battery 480 Vdc (240 cells) for Powerware 9315 500 String Voltage 420 Vdc (210 cells) for Powerware 9315 400 Float Charging 2.25 Vdc per cell...
  • Page 86 Product Specifications This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 10−4 EATON Powerware ®...

  • Page 87: Responding To System Events

    Bypass Under Frequency Clear Inverter Over Frequency Clear Bypass Under Frequency Inverter Under Frequency Battery DC Under Voltage Clear Inverter Under Frequency Clear Battery DC Under Voltage 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 11−1 EATON Powerware ®...
  • Page 88 Clear Rectifier DC Under Voltage Clear Input AC Under Voltage Rectifier Over Temperature Input AC Over Frequency Clear Rectifier Over Temperature Clear Input AC Over Frequency 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 11−2 EATON Powerware ®...
  • Page 89 Clear Output Under Frequency Fan Failure 3W AC Over Voltage Clear Fan Failure Clear 3W AC Over Voltage 3W AC Under Voltage Clear 3W AC Under Voltage 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 11−3 EATON Powerware ®...
  • Page 90 Building Alarm 6 Clear Building Alarm 6 Rectifier Network Down Rectifier Network Clear Inverter Network Down Inverter Network Clear Monitor Network Down Monitor Network Clear 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 11−4 EATON Powerware ®...
  • Page 91 The breaker and contactors open (you can hear them opening). The CB1 switch trips, and the Load Off PUSH TO RESET button on the UPS Control Panel pops out. The UPS system shuts down. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 12−1 EATON Powerware ®...

  • Page 92: Resetting The Ups System After Load Off

    TRIPPED position. 3. The UPS system is now reset. To restart the UPS system, follow the procedure in Chapter 4, Starting and Stopping the UPS." 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com 12−2 EATON Powerware ®...

  • Page 93: Warranty

    Powerware−built battery cabinets (individually and collectively, the "Warranted Items") are free from defects in material and workmanship. If, in the opinion of Eaton, a Warranted Item is defective and the defect is within the terms of this Warranty, Eaton’s sole obligation will be to repair or replace such defective item (including by providing service, parts, and labor, as applicable), at the option of Eaton.
  • Page 94 Warranty This page intentionally left blank. 9315 UPS (300–500 kVA) Operation Manual S 164201119 Rev F www.powerware.com W−2 EATON Powerware ®...
  • Page 96 *164201119F* 164201119 F...
