Powerware 9315 UPS
Parallel Capacity/Redundant System
Installation and Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Powerware 9315 and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton Powerware 9315

Summary of Contents for Eaton Powerware 9315

  • Page 1 ® Powerware 9315 UPS Parallel Capacity/Redundant System Installation and Operation Manual...
  • Page 2 WARNING This is a product for restricted sales distribution to informed partners. Installation restrictions or additional measures may be needed to prevent disturbances. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 3: Table Of Contents

    ........5−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150...
  • Page 4 ....... 9−5 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 5 10−1 10.2 Operation of SBM with Powerware 9315−200 thru 9315−500 UPMs ........
  • Page 6 ....... 14−5 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 7 Appendix A − Customer Information ......A−1 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 8 ......9−1 Figure 9−2. Parts of the LCD Screen (Typical for Powerware 9315 300 480/480V Unit) .
  • Page 9 ........13−9 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150...
  • Page 10 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 11: Introduction

    Introduction The Powerware 9315 Parallel Capacity/Redundant System online power protection can be utilized to prevent loss of valuable electronic information, minimize equipment downtime, and/or minimize the adverse effect on equipment production due to unexpected power problems. The Powerware 9315 Parallel Capacity/Redundant System continually monitors incoming electrical power and removes the surges, spikes, sags, and other irregularities that are inherent in commercial utility power.

  • Page 12: Figure 1. Typical Parallel Capacity/Redundant System

    POWERNET DUAL REDUNDANT NETWORK SBM INTERFACE − TERMINAL BLOCK TB1 UPM INTERFACE − TERMINAL BLOCK TB1 NOTE: Accommodates one to eight UPMs. Four UPM system shown. Figure 1. Typical Parallel Capacity/Redundant System EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 13: Basic System Configurations

    Chapter 5 − Installing a Relay Interface Module − contains information for installing the optional Relay Interface Panel (RIM). • Chapter 6 − Installing a Supervisory Contact Module − contains information for installing the optional Supervisory Contact Module (SCM). EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 14: Appendix A − Customer Information

    Read through each procedure before you begin. Perform only those procedures that apply to the Parallel Capacity/Redundant system you are installing or operating. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 15: Conventions Used In This Manual

    The system is not intended for outdoor use. • The operating environment should be maintained within the parameters stated in this manual and the Powerware 9315 Operation manual provided with the UPS system. • Keep the cabinet doors closed to ensure proper cooling airflow and to protect personnel from dangerous voltages inside the unit.

  • Page 16: For More Information

    If you have a question about any of the information in this manual, or if you have a question this manual does not answer, please call Powerware Corporation Field Service: United States 1-800-843-9433 Canada 1-800-461-9166 Outside the U.S. Call your local representative EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 17: Section I

    Section I Installation EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 18 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 19: Getting Started

    UPMs. First understand how to install the UPMs before installing the SBM. The information in Chapter 2 of this manual is a guide to installation of the SBM to the UPMs. EATON Powerware 9315 Parallel Capacity/Redundant System 1−1 164201150...

  • Page 20: Preparing Your Site

    Control wiring for PowerNet, EPO and optional accessories (such as building alarms, monitoring interface and Maintenance Bypass control) should be connected at the customer interface panel at the top of the SBM. EATON Powerware 9315 Parallel Capacity/Redundant System 1−2 164201150 Rev. E www.powerware.com...

  • Page 21: Inspecting And Unpacking Each Cabinet

    Set each pallet on a firm, level surface, allowing a minimum clearance of 4.6m (15 ft) on each side for removing the cabinets from the pallets. Cut the steel bands around each cabinet. EATON Powerware 9315 Parallel Capacity/Redundant System 1−3 164201150...
  • Page 22 Customer Service Department immediately to determine the extent of the damage and its impact upon further installation. NOTE: While awaiting installation, protect the unpacked SBM and UPS cabinets from moisture, dust, and other harmful contaminants. EATON Powerware 9315 Parallel Capacity/Redundant System 1−4 164201150 Rev. E www.powerware.com...

  • Page 23: Installing The Parallel Capacity/Redundant System 2−1

    UPMs. Refer to Table H in Appendix A for equipment weight and point loading. • Details about control wiring are provided in each procedure for connecting options and features. Drawings 164201150−13 and 164201150−14 in Appendix A identify the control wiring terminations. EATON Powerware 9315 Parallel Capacity/Redundant System 2−1 164201150 Rev. E www.powerware.com...

  • Page 24: Installing The Sbm Cabinet

    Move SMB to final installed location on the right side of the SBM cabinet using forklift jacks between foam cushions on the bottom of the unit. Remove hardware securing cabinet to cushioned pallet. 2−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 25: Installing The Upm Cabinets

    Install batteries in accordance with all applicable codes and regulations, including the National Electrical Code (NEC), Article 480. EATON Powerware 9315 Parallel Capacity/Redundant System 2−3 164201150 Rev. E www.powerware.com...

  • Page 26: Installing Smb Wiring

    Service personnel may request a copy of the completed Installation Checklist to be sure you have completed all applicable equipment installation. NOTE: The Installation Checklist MUST be completed prior to starting the Parallel Capacity/Redundant system for the first time. 2−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 27: Installation Checklist

    A remote battery disconnect control is mounted in its installed location and its wiring is terminated inside the UPS and battery cabinet. (OPTIONAL) Startup and operational checks performed by authorized service personnel. EATON Powerware 9315 Parallel Capacity/Redundant System 2−5 164201150...
  • Page 28 Notes ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ 2−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 29: Installing A Remote Epo Control 3−1

    SBM to other equipment Figure 3−1. Remote EPO Control NOTE: Before installing an Remote EPO, be sure you have prepared the SBM according to the instructions in Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 3−1 164201150 Rev. E www.powerware.com...
  • Page 30 Table 3−2. Remote EPO switch wiring must be in accordance with UL Class I requirements. Secure the SBM by reversing all steps taken to prepare it for Remote EPO installation. EATON Powerware 9315 Parallel Capacity/Redundant System 3−2 164201150 Rev. E www.powerware.com...

  • Page 31: Installing A Remote Monitor Panel (Optional)

    Figure 4−1 shows an RMP . Drawing 164201150−17 in Appendix A shows the enclosure dimensions and knockout patterns. Table 4−1. Optional Monitoring Accessories Number and Type of Accessories Permitted Remote Monitor Panel Relay Interface Module Supervisory Contact Module EATON Powerware 9315 Parallel Capacity/Redundant System 4−1 164201150 Rev. E www.powerware.com...

  • Page 32: Figure 4−1. Remote Monitor Panel (Rmp)

    FLUSH MOUNT SURFACE MOUNT (FOR HANGING) WIRES MUST BE TWISTED Figure 4−1. Remote Monitor Panel (RMP) EATON Powerware 9315 Parallel Capacity/Redundant System 4−2 164201150 Rev. E www.powerware.com...

  • Page 33: To Install An Rmp

    Customer Interface Panel. Connect to Port 1 (DB−9) on Customer Interface Panel FUSE TERMINAL BLOCK (TB3) Figure 4−2. Terminal Block Bracket EATON Powerware 9315 Parallel Capacity/Redundant System 4−3 164201150 Rev. E www.powerware.com...
  • Page 34 6, respectively; otherwise, secure the SBM by reversing the steps contained in procedure To Prepare the SBM for Wiring to an RMP , RIM, SCM, or Remote EPO" of Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 4−4 164201150...

  • Page 35: Installing A Relay Interface Module (Optional)

    15-PIN D-SUB AT UPS CONNECTORS Figure 5−1. Relay Interface Module NOTE: Before installing an RIM, be sure you have prepared the SBM according to the instructions in Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 5−1 164201150 Rev. E www.powerware.com...

  • Page 36: To Install A Rim

    Customer Interface Panel. Connect to Port 1 (DB−9) on Customer Interface Panel FUSE TERMINAL BLOCK (TB3) Figure 5−2. Terminal Block Bracket EATON Powerware 9315 Parallel Capacity/Redundant System 5−2 164201150 Rev. E www.powerware.com...
  • Page 37 4 or 6, respectively; otherwise, secure the SSBM by reversing the steps contained in procedure To Prepare the SBM for Wiring to an RMP , RIM, SCM, or Remote EPO" of Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 5−3 164201150...
  • Page 38 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 5−4 164201150 Rev. E www.powerware.com...

  • Page 39: Installing A Supervisory Contact Module

    (FOR HANGING) WIRES MUST BE TWISTED Figure 6−1. Supervisory Contact Module NOTE: Before installing an SCM, be sure you have prepared the SBM according to the instructions in Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 6−1 164201150 Rev. E www.powerware.com...

  • Page 40: To Install A Supervisory Contact Module

    Customer Interface Panel. Connect to Port 1 (DB−9) on Customer Interface Panel FUSE TERMINAL BLOCK (TB3) Figure 6−2. Terminal Block Bracket EATON Powerware 9315 Parallel Capacity/Redundant System 6−2 164201150 Rev. E www.powerware.com...
  • Page 41 4 or 5, respectively; otherwise, secure the SSBM by reversing the steps contained in procedure To Prepare the SBM for Wiring to an RMP , RIM, SCM, or Remote EPO" of Chapter 2. EATON Powerware 9315 Parallel Capacity/Redundant System 6−3 164201150...

  • Page 42: Figure 6−3. Supervisory Contact Module Tb2

    Note: Supervisory contacts are rated at 2.0 amps at 28 Vdc or 120 Vac and 0.15 amp at 115 Vdc. Supervisory contacts require external power supply. Internal 24 Vdc is not capable of supplying contact current. Figure 6−3. Supervisory Contact Module TB2 EATON Powerware 9315 Parallel Capacity/Redundant System 6−4 164201150 Rev. E www.powerware.com...
  • Page 43 Section II Operation EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 44 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 45: Understanding Parallel Capacity/Redundant System Operation

    If an SCR shorts, the breaker will open so that the UPMs will not backfeed the bypass source, dropping the load when a utility outage occurs. EATON Powerware 9315 Parallel Capacity/Redundant System 7−1 164201150...

  • Page 46: Normal, Battery, And Bypass Modes With Parallel Operation: 7−2

    In Maintenance Bypass mode (optional), the SMB bypass supplies the load and isolates the SBM and UPMs for maintenance purposes. The following descriptions provide the Parallel Capacity/Redundant system operating mode differences. 7−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 47: Normal Mode

    If the UPMs becomes overloaded or unavailable, the SBM switches to Bypass mode. The SBM automatically returns to Normal mode when the error condition is cleared and system operation is restored within specified limits. EATON Powerware 9315 Parallel Capacity/Redundant System 7−3 164201150...

  • Page 48: Bypass Mode

    Bypass mode is a normal operating mode, and not an alarm condition. However, if the SBM is unable to return to Normal mode following an automatic transfer to Bypass mode, an alarm condition will be recorded. 7−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 49: Battery Mode

    Normal mode and alarm indications clear. However, the process of returning to Normal mode is not instantaneous. The UPMs gradually draw increasing power from the incoming utility until Normal mode is achieved. EATON Powerware 9315 Parallel Capacity/Redundant System 7−5 164201150...

  • Page 50: Optional Modes Of Parallel Operation: Maintenance Bypass And Redundant Cbp

    In Redundant CBP mode (optional), if the CBP breaker fails to close during a manual or automatic operation, the SSBM automatically closes the MBP breaker to maintain power to the critical load. 7−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 51: Maintenance Bypass Mode (Optional)

    UPM2 BATT UPM3 BATT UPM4 (open) BATT OUTPUT TO CRITICAL LOAD Path of Electrical Power Figure 7−4. Path of Current Through the Parallel Capacity/Redundant System in Maintenance Bypass Mode. EATON Powerware 9315 Parallel Capacity/Redundant System 7−7 164201150 Rev. E www.powerware.com...

  • Page 52: Redundant Cbp Mode (Optional)

    After the CBP breaker has been repaired, the UPS system can be transferred from Maintenance Bypass mode to Bypass mode as described above. Figure 7−5 shows the path of electrical power through the Parallel Capacity/Redundant system when operating in Maintenance Bypass mode. 7−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 53 (open) UPM2 BATT (open) UPM3 BATT UPM4 BATT Path of Electrical Power OUTPUT TO CRITICAL LOAD Parallel Capacity/Redundant System Figure 7−5. Path of Current Through the Redundant CBP Mode. EATON Powerware 9315 Parallel Capacity/Redundant System 7−9 164201150 Rev. E www.powerware.com...
  • Page 54 This Page Intentionally Left Blank. 7−10 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 55: Operational Controls And Features

    FBP is used to prevent power from being feed back to the UPMs in the event the static switch fails. These breakers are electrically controlled by the SBM and are automatic in operation. EATON Powerware 9315 Parallel Capacity/Redundant System 8−1 164201150...

  • Page 56: Powernet

    Class 2 wiring methods. Class 2 wiring can be routed through the top or bottom of each cabinet. 8−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 57: Options And Accessories

    An optional modem is available for use with the Remote Notification feature described in Chapter 14, Remote Notification". Refer to the manual supplied with the modem for modem operating instructions. EATON Powerware 9315 Parallel Capacity/Redundant System 8−3 164201150 Rev. E www.powerware.com...

  • Page 58: Figure 8−1. 1200A Sbm Controls And Indicators

    CONTROL PANEL UPM OUTPUT BREAKER BACKFEED PROTECTION BREAKER SYSTEM BYPASS BREAKER Figure 8−1. 1200A SBM Controls and Indicators 8−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 59: Figure 8−2. 2000A Sbm Controls And Indicators

    BACKFEED SYSTEM CONTROL PROTECTION BYPASS BREAKER PANEL BREAKER OUTPUT BREAKER Figure 8−2. 2000A SBM Controls and Indicators EATON Powerware 9315 Parallel Capacity/Redundant System 8−5 164201150 Rev. E www.powerware.com...

  • Page 60: Safety Considerations

    Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and outside of the equipment. • Always conform to the more detailed safety precautions described in Important Safety Instructions" section of Chapter 15. 8−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 61: Symbols, Controls, And Indicators

    Stop and refer to the Operator’s Manual for more information. RISK OF ELECTRIC SHOCK There is a risk of electric shock present, and you should observe associated warnings. The UPS contains high voltages. EATON Powerware 9315 Parallel Capacity/Redundant System 8−7 164201150 Rev. E www.powerware.com...
  • Page 62 This Page Intentionally Left Blank. 8−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 63: Using The Sbm Control Panel

    (4) a vertical column of backlit status indicators, (5) a SYSTEM MODE key switch, (6) and a PUSH IN TO RESET pushbutton. The following sections describe the Monitor Panel in detail. EATON Powerware 9315 Parallel Capacity/Redundant System 9−1 164201150 Rev. E www.powerware.com...

  • Page 64: Using The Lcd Screen

    Meters Events Statistics Graphics Setup Figure 9−2. Parts of the LCD Screen (Typical for Powerware 9315 300 480/480V Unit) The UPS status area contains three lines that display the current state of the UPS. The first line shows the present operational mode of the UPS. The second line shows the highest level of the current active alarms, and the third line shows any notices the UPS has posted.

  • Page 65: Using The Pushbuttons

    Use the pushbuttons to adjust the contrast on the LCD screen. Hold down the pushbutton, then press the pushbutton to increase the contrast or the pushbutton to decrease the contrast. EATON Powerware 9315 Parallel Capacity/Redundant System 9−3 164201150 Rev. E www.powerware.com...

  • Page 66: Reading The Status Indicators

    If any indicator does not light, its LED may need to be replaced. Contact Customer Service if you have a problem with the indicator lamps. 9−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 67: Using The Menu Options

    Meters Events Statistics Graphics Setup Figure 9−3. System Meters Screen (Typical for Powerware 9315 300 480/480V Unit) The Input area shows the phase-to-phase voltage, frequency, and phase current of the incoming utility, followed by the KVA, KW, and power factor measurements. The output area shows the same information for the power being output by the UPS.

  • Page 68: Figure 9−4. Load Amps Meters Screen

    Output Current Battery Minutes 125% 48.5 100% Meters System Load Amps Versions Phase A Phase B Phase C Meters Events Statistics Graphics Setup Figure 9−4. Load Amps Meters Screen 9−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 69: Figure 9−5. Versions Meters Screen

    Minutes 48.5 Version Part Number Monitor 01.17 143650369 Rectifier ***** 143650347 Inverter ***** 143650348 Meter History System Loading Versions Meters Events Statistics Graphics Setup Figure 9−5. Versions Meters Screen EATON Powerware 9315 Parallel Capacity/Redundant System 9−7 164201150 Rev. E www.powerware.com...

  • Page 70: Figure 9−6. Event History Log Screen

    When the scroll bar is in the menu box, the return arrow is in the information area. When the scroll bar is in the information area, you can press the pushbuttons to scroll through the Event History log. 9−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 71: Figure 9−7. Active System Events Screen

    Battery Minutes NOTICE: Input power unavailable 48.5 NOTICE: Bypass Not Available ALARM: Shutdown Imminent Events History Active Versions Meters Events Statistics Graphics Setup Figure 9−7. Active System Events Screen EATON Powerware 9315 Parallel Capacity/Redundant System 9−9 164201150 Rev. E www.powerware.com...

  • Page 72: Figure 9−8. Unit Statistics Screen

    UPS was on bypass, battery, or generator, and the amount of time the UPS logic has been functioning since the start date. The lower right column shows the percent of availability of the UPS and the bypass source. 9−10 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 73: Figure 9−9. Mimic Screen

    Mimic screen is dependent on the actual number of units installed at location. Also all alarms are shown for information purposes only. Only actual alarms would be shown in the installed instance. EATON Powerware 9315 Parallel Capacity/Redundant System 9−11 164201150...

  • Page 74: Figure 9−10. Time Setup Screen

    (make it a lower value), press the pushbutton. If you want to save the settings upon exit from this screen, be sure the SAVE field is set to YES. 9−12 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 75: Figure 9−11. Port Setup Screen

    SAVE field is set to YES. The setup screens for Port 1 and Port 2 are identical. For detailed information about configuring the serial ports, refer to Chapter 13, Serial Communications." EATON Powerware 9315 Parallel Capacity/Redundant System 9−13 164201150...
  • Page 76 This Page Intentionally Left Blank. 9−14 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 77: Operating Instructions For The Parallel Capacity/Redundant System

    FBP will charge, if not already charged. Close upstream UPM and SBM Bypass input feeder circuit breakers. Observe SBM monitor screen becoming active and Alarm and Notice messages scrolling. EATON Powerware 9315 Parallel Capacity/Redundant System 10−1 164201150 Rev. E www.powerware.com...

  • Page 78: Manual Start

    If message appears, turn the SBM SYSTEM MODE key switch to NORMAL momentarily. Observe that breaker CBS closes and breaker CBP opens. System is now in Normal mode, with the critical load being supplied power from the UPMs. 10−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 79: Auto Start

    UPMs and system is operating in normal mode. NOTE: If transfer is not completed within one minute, the SYSTEM MODE key switch must be turned momentarily to NORMAL again to achieve normal operation. EATON Powerware 9315 Parallel Capacity/Redundant System 10−3 164201150 Rev. E www.powerware.com...

  • Page 80: Single Upm Shutdown

    To shutdown last UPM, press last UPM LOAD OFF pushbutton. WARNING Power is present at UPM CB1 input, until upstream UPM input feeder circuit breaker is opened. Fans and load side of K3 will still have voltage present. 10−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 81: Restarting A Single Upm

    Resetting the UPM after Load Off" of this chapter before starting the UPS. NOTE: The UPM Remote Emergency Load Off option functions the same way as the LOAD OFF pushbutton on the Monitor Panel. EATON Powerware 9315 Parallel Capacity/Redundant System 10−5 164201150...

  • Page 82: To Use The Load Off Pushbutton

    Power to the critical load is de-energized and UPMs powered down. UPM CB1 breakers trip and the UPM is cut off from utility power. This function requires additional EPO kit available from Powerware. 10−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 83: To Use The Sbm Emergency Upm Off Pushbutton

    OFF. The switches should be difficult to move from the TRIPPED position. The Parallel Capacity/Redundant system is now reset. To restart the Parallel Capacity/Redundant system, follow the procedure at the beginning of this Chapter. EATON Powerware 9315 Parallel Capacity/Redundant System 10−7 164201150 Rev. E www.powerware.com...

  • Page 84: Initial Setup

    Observe SBM monitor screen becoming active and Alarm and Notice messages scrolling. Observe all UPM monitor screens become active as an indication of logic power. Verify all UPMs are shown on the SBM mimic screen. 10−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 85: Manual Start

    On SBM monitor screen, check for On Bypass, UPMs Ready message. If message appears, turn the SBM SYSTEM MODE key switch to NORMAL momentarily. Observe that breaker CBS closes, breaker CBP opens, and the SSW is turned off. EATON Powerware 9315 Parallel Capacity/Redundant System 10−9 164201150 Rev. E www.powerware.com...

  • Page 86: Auto Start

    On SBM monitor screen, verify UPS OFF, message appears. WARNING Power is present at UPM CB1 input until upstream UPM input feeder circuit breaker is opened. The load side of CB3 still has voltage present. 10−10 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 87: Sbm Shutdown To Bypass

    Normal mode. If UPS is not in Autorestart, turn the MODE key switch to NORMAL for three seconds to transfer to Normal mode. The UPM is now operating in Normal mode. On SBM mimic screen, check for presence of UPM. EATON Powerware 9315 Parallel Capacity/Redundant System 10−11 164201150 Rev. E www.powerware.com...

  • Page 88: Using The Upm Emergency Upm Off Pushbutton

    Press the EMERGENCY UPM OFF PUSH TO RESET pushbutton until it clicks in and remains recessed. The UPM is now reset. To restart the UPM, follow the procedure in this chapter, Restarting a Single UPM." 10−12 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 89: Using The Sbm Emergency Upm Off Pushbutton

    Press the EMERGENCY UPM OFF pushbutton. Breakers open and close (you can hear them opening and closing) and the Emergency UPM Off PUSH IN TO RESET pushbutton on the SBM Control Panel pops out. EATON Powerware 9315 Parallel Capacity/Redundant System 10−13 164201150 Rev. E www.powerware.com...

  • Page 90: Resetting The Parallel Capacity/Redundant System After

    Press the Emergency UPM Off PUSH IN TO RESET pushbutton until it clicks in and remains recessed. The Parallel Capacity/Redundant system is now reset. To restart the Parallel Capacity/Redundant system, follow the procedure at the beginning of this chapter. 10−14 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 91: Transfer To Maintenance Bypass

    Ensure SBM is on bypass. On SBM, turn the Maintenance Bypass key switch to the right (From Maintenance) momentarily. Observe MIS closes and MBP opens. System is now in normal mode. EATON Powerware 9315 Parallel Capacity/Redundant System 10−15 164201150 Rev. E www.powerware.com...
  • Page 92 This Page Intentionally Left Blank. 10−16 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 93: Using Features And Options

    Relay 2 is normally energized and is only deenergized for an alarm condition. CAUTION Contacts should not be opened in excess of 30VAC or 42.4V peak AC or DC @1A maximum. EATON Powerware 9315 Parallel Capacity/Redundant System 11−1 164201150 Rev. E www.powerware.com...

  • Page 94: Remote Monitor Panel (Optional)

    Figure 11−1 shows an RMP . Figure 11−1. Remote Monitor Panel Table 11−1. Optional Monitoring Accessories Number and Type of Accessories Permitted Remote Monitor Panel Relay Interface Module Supervisory Contact Module EATON Powerware 9315 Parallel Capacity/Redundant System 11−2 164201150 Rev. E www.powerware.com...
  • Page 95 The UPS is preparing to shut down because the UPS is in Battery mode and the DC voltage is approaching its low limit. This light is accompanied by an audible alarm horn. EATON Powerware 9315 Parallel Capacity/Redundant System 11−3 164201150 Rev. E www.powerware.com...

  • Page 96: Relay Interface Module (Optional)

    (pins 6 and 15) Contacts are closed when Utility Failure is detected. • BATTERY WEAK (pins 5 and 14) Contacts are closed when approximately 2 minutes of battery time is remaining, before the critical load is lost. EATON Powerware 9315 Parallel Capacity/Redundant System 11−4 164201150 Rev. E www.powerware.com...

  • Page 97: Figure 11−3. Supervisory Contact Module

    ON BYPASS TB2−19 through TB2−21 • SHUTDOWN IMMINENT TB2−22 through TB2−24 Refer to the applicable Powerware 9315 Installation manual chapter, Installing a Supervisory Contact Module, for TB2 contact configurations. EATON Powerware 9315 Parallel Capacity/Redundant System 11−5 164201150 Rev. E www.powerware.com...

  • Page 98: Common Battery Racks

    Note 3: The UPM DC disconnect trip signal from TB4, points 1 and 2 (shunt trip) or TB4, points 1 and 3 (UV trip) must be connected to the DC source disconnect device(s). Each UPM must have a separate disconnect device. EATON Powerware 9315 Parallel Capacity/Redundant System 11−6 164201150 Rev. E www.powerware.com...

  • Page 99: Responding To System Events

    When an alarm occurs, you should first check these indicators to see what type of event has taken place. (For descriptions of the status indicators, refer to the Reading the Status Indicators" section of Chapter 9.) EATON Powerware 9315 Parallel Capacity/Redundant System 12−1 164201150...

  • Page 100: System Event Messages

    Bypass Control Failed Check Unit Setup Bypass Contactor (K4) Fail Battery Ground Fault 100% Overload Shutdown 125% Overload Shutdown Over Temperature Shutdown Network Sync Failure Inverter Calibration Required Inverter Setup Required 12−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 101 Check KW Sensing Check Parallel Setup Parallel System Overload On Battery more than 30 Seconds Check UPM Breaker (CBS) AUX Check Bypass Breaker (CBP) AUX Monitor Calibration Required Monitor Setup Required EATON Powerware 9315 Parallel Capacity/Redundant System 12−3 164201150 Rev. E www.powerware.com...
  • Page 102 PowerNet Channel A TX Down PowerNet Channel B TX Down STSW NOT Available STSW SCR SHORTED Load Over 100% Load Over 125% STSW Disconnected K1 Relay Failure PowerNode Calibration Required PowerNode Setup Required 12−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 103 UPM 1 Phone Home UPM 2 Phone Home UPM 3 Phone Home UPM 4 Phone Home UPM 5 Phone Home UPM 6 Phone Home UPM 7 Phone Home UPM 8 Phone Home EATON Powerware 9315 Parallel Capacity/Redundant System 12−5 164201150 Rev. E www.powerware.com...
  • Page 104 Power Supply Under Voltage Input Transient DC Voltage Low DC Voltage High Equalizing Battery Testing Battery Battery Test Failed Input/Battery Current Limit Reduced Input Current Limit Rct. Logic Power Failure 12−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 105 Building Alarm 5 Active Building Alarm 6 Active Testing Battery Battery Test Aborted (load) Battery Test Aborted (utility) Battery Passed Test ##Printing Sampled Data Other UPS Bypass Not Available Loss of Redundancy EATON Powerware 9315 Parallel Capacity/Redundant System 12−7 164201150 Rev. E www.powerware.com...
  • Page 106 Bypass Under Frequency Bypass is Not Available Not Enough UPMs System NOT Redundant PowerNode Calibration Fail PowerNode Calibration Pass No Bypass Sync Check EPO Reset Pn. Logic Power Failure 12−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 107: Serial Communications

    SBM should be male. Figure 13−1 shows the pin assignments for Port 1, and Table 13−1 describes them. Figure 13−2 shows the pin assignments for Port 2, and Table 13−2 describes them. EATON Powerware 9315 Parallel Capacity/Redundant System 13−1 164201150...

  • Page 108: Figure 13−1. Port 1 Pin Assignments

    Pin # Symbol Description Comments +24V + 24 volts DC Transmit Data Input to UPS Receive Data Output from UPS Return 485+ RS485 + Data 485− RS485 − Data Return EATON Powerware 9315 Parallel Capacity/Redundant System 13−2 164201150 Rev. E www.powerware.com...

  • Page 109: Figure 13−2. Port 2 Pin Assignments

    Data Terminal Ready Input to UPS − typically not used by UPS −12V − 12 volts Output from UPS − always true NOTE: Pins 5 and 6 are tied together internally. EATON Powerware 9315 Parallel Capacity/Redundant System 13−3 164201150 Rev. E www.powerware.com...

  • Page 110: Configuring The Serial Ports

    To scroll through the available options for that setting, press the pushbutton. To save the settings upon exit from this screen, be sure the Save field is set to YES. EATON Powerware 9315 Parallel Capacity/Redundant System 13−4 164201150 Rev. E www.powerware.com...

  • Page 111: Modes

    300 baud is not recommended for any mode except Remote Monitor. You can select a baud rate of 300, 1200, 2400, 4800, 9600, or 19,200. EATON Powerware 9315 Parallel Capacity/Redundant System 13−5 164201150...

  • Page 112: Data/Stop

    9600 baud 8/1 Handshaking Disabled Each communications port on the SBM operates in one of five modes which you select when configuring the port using the Setup Port screen. EATON Powerware 9315 Parallel Capacity/Redundant System 13−6 164201150 Rev. E www.powerware.com...

  • Page 113: Terminal Mode

    Prints the current system meters with a header Ctrl+A Prints all system information Ctrl+B Prints Battery Test Log To use a key combination, hold down the Control key and press the letter key. EATON Powerware 9315 Parallel Capacity/Redundant System 13−7 164201150 Rev. E www.powerware.com...

  • Page 114: Entire Log (Ctrl

    STATUS: Inverter Contactor (3) Closed 16:43:15.8 STATUS: Bypass Contactor (K4) Open 16:43:42.4 STATUS: Inverter Normal 16:44:29.1 4001 JUN 04 12:16:35.9 NOTICE: Room High Temperature Figure 13−4. Event History Log EATON Powerware 9315 Parallel Capacity/Redundant System 13−8 164201150 Rev. E www.powerware.com...

  • Page 115: Meters Printout (Ctrl

    This key sequence prints a listing of all available serial data. This printout contains the information shown on the Event History Log and Meters screens of the SBM (both Figures 13−4 and 13−5). EATON Powerware 9315 Parallel Capacity/Redundant System 13−9 164201150...

  • Page 116: System Configuration

    If 1 is entered at the prompt, you can program the building alarm functions: Program Building Alarms 1. Enable/Disable Default Functions 2. Customize Alarm Messages 3. Return to Main Menu Enter Selection: EATON Powerware 9315 Parallel Capacity/Redundant System 13−10 164201150 Rev. E www.powerware.com...

  • Page 117: Enable/Disable Default Functions

    Enter <CR> for No Change Enter Selection: The line following the Enabled Building Alarm Number(s) label indicates which building alarms are currently enabled. (In this example, Building Alarms 1 and 4 are enabled.) EATON Powerware 9315 Parallel Capacity/Redundant System 13−11 164201150 Rev. E www.powerware.com...

  • Page 118: Customize Alarm Messages

    If an E is entered at the prompt, the custom messages will be used for the building alarm. If a D is entered, the default messages will be used for the building alarm. EATON Powerware 9315 Parallel Capacity/Redundant System 13−12 164201150 Rev.

  • Page 119: Program Unit Name

    NOTE: Password must be six characters in length. <CR> to return with no change. The password will be changed if the user enters and verifies the password. The entry must be six characters. EATON Powerware 9315 Parallel Capacity/Redundant System 13−13 164201150 Rev. E www.powerware.com...

  • Page 120: Battery Test Setup

    If 5 is selected and there are no tests scheduled, the following will be displayed: No Battery Test Scheduled Enter <CR> to return to Battery Test Setup Menu NOTE: The unit will only perform one battery test in any 24 hour period. EATON Powerware 9315 Parallel Capacity/Redundant System 13−14 164201150 Rev. E www.powerware.com...

  • Page 121: Modify Low Battery Time

    For a list of products available, contact your sales representative. 13.9 Remote Monitor Mode This mode provides the interface for the RMP , RIM, or SCM described earlier. EATON Powerware 9315 Parallel Capacity/Redundant System 13−15 164201150 Rev. E www.powerware.com...
  • Page 122 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 13−16 164201150 Rev. E www.powerware.com...

  • Page 123: Remote Notification

    Numeric paging support allows the SBM to call a paging service and send numeric messages. The Housekeeping function maintains the link between the SBM and modem. EATON Powerware 9315 Parallel Capacity/Redundant System 14−1 164201150 Rev. E www.powerware.com...

  • Page 124: Remote Notification Features

    Refer to the Call Out" section of this chapter for more information when calling a pager or if a failed connection to a PC terminal. 14−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 125: Call Out

    The Call Out process can be terminated at any time by calling into the SBM and sending the reset command (press and hold [CTRL] and press [R]) or by turning the key switch on the front of the SBM. EATON Powerware 9315 Parallel Capacity/Redundant System 14−3 164201150...

  • Page 126: Housekeeping

    An alternative to purchasing a cable is to build your own serial cable using the following pin out description: Male DB25 Male DB25 pin 7 pin 7 pin 2 pin 2 pin 3 pin 2 14−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 127: Configuring The Modem

    Basic Modem Configuration The basic modem should be a plug and play type. All setup is done by the UPS. Only the initial phone number needs to be entered by the user. EATON Powerware 9315 Parallel Capacity/Redundant System 14−5 164201150...

  • Page 128: Configuring The Modem To Call A Remote Computer

    NOTE: To set up a group one or group two pager number, refer to Configuring the Modem to Call a Numeric Pager" section of this chapter. 14−6 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 129: Configuring The Modem To Call A Numeric Pager

    NOTE: To set up a group one or group two number to call a computer, refer to Configuring the Modem to Call a Remote Computer" section of this chapter. EATON Powerware 9315 Parallel Capacity/Redundant System 14−7 164201150...

  • Page 130: Final Modem Configuration

    8. Confirm that the modem responds with OK" or 0" (zero) and that the AT" is not echoed back to the terminal. 9. Key in [A], [T], [&], [W], [0] (zero), then press [ENTER]. 10. Confirm that the modem responds with OK" or 0" (zero). 14−8 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 131: Sbm Setup Configuration

    Serial Communications"). If using a standard serial cable, a null modem adapter is required for the connection to the modem. The Powerware 9315 SBM can only use serial Port 2, DB−25F, for the Remote Notification option. This connection is located on the Customer Interface Panel at the top right of the SBM cabinet.

  • Page 132: User Selected Events

    14.6.1 User Selected Events Insert a check at each alarm or notice in the appropriate Group 1 or Group 2 block to indicate the configuration of your SBM. 14−10 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 133 Bypass Contactor (K4) Phase C Current Limit Failed Battery Contactor (K2) Phase C Current Limit Failed Bypass Control Failed Bypass Phase Rotation Go To Bypass Active Battery Ground Fault EATON Powerware 9315 Parallel Capacity/Redundant System 14−11 164201150 Rev. E www.powerware.com...
  • Page 134 Required Temperature Sensor Input Under Frequency Failure Input/Battery Current Limit Logic Power Failed Power Supply Over Voltage Power Supply Under Voltage Rectifier 1.12 Reduced Input Current Limit Testing Battery 14−12 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 135 Output Under Frequency Power Off Switch Rectifier Network Down Testing Battery Three Wire AC Over Voltage Three Wire AC Under Voltage Three Wire Over Freq. Three Wire Under Freq. EATON Powerware 9315 Parallel Capacity/Redundant System 14−13 164201150 Rev. E www.powerware.com...

  • Page 137: Maintaining The Parallel Capacity/Redundant System

    Powerware field service office. If the rack requires service, refer to the battery rack manufacturer’s operating manual for instructions on battery rack maintenance, or contact your local Powerware field service office. EATON Powerware 9315 Parallel Capacity/Redundant System 15−1 164201150 Rev. E www.powerware.com...
  • Page 138 Suivre les précautions qui s’imposent. • Pour le remplacement, utiliser le même nombre et modéle des batteries. • L’élimination des batteries est règlementée. Consulter les codes locaux à cet effet. 15−2 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 139: Performing Preventive Maintenance

    BATTERY maintenance: Contact your nearest Powerware field service office for battery maintenance. Battery replacement and maintenance should be performed only by authorized service personnel. EATON Powerware 9315 Parallel Capacity/Redundant System 15−3 164201150 Rev. E www.powerware.com...

  • Page 140: Maintenance Training

    For more information about training and other services, contact the Powerware Corporation Training Coordinator in Raleigh, North Carolina, or call Powerware Corporation field service at 1−800−843−9433. 15−4 EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...

  • Page 141: Product Specifications

    Input Frequency Range Input Current Model 600: 600 Amps Model 800: 800 Amps Model 1000: 1000 Amps Model 1200: 1200 Amps Model 1600: 1600 Amps Model 2000: 2000 Amps EATON Powerware 9315 Parallel Capacity/Redundant System 16−1 164201150 Rev. E www.powerware.com...

  • Page 142: Sbm Output

    A devices Electrostatic Discharge (ESD) Meets IEC 801−2 specifications. Withstands up Immunity to 25 kV without damage and with no disturbance or adverse effect to the critical load. EATON Powerware 9315 Parallel Capacity/Redundant System 16−2 164201150 Rev. E www.powerware.com...
  • Page 143 • 164201150−13 SBM Customer Interface Panel • 164201150−14 UPM PowerNet Interface Panel Powerware 9315−200 to −500 UPMs • 164201150−15 UPM CAN Interface: Powerware 9315 625/750 UPMs • 164201150−16 Remote Emergency Power Off • 164201150−17 Remote Monitor Panel • 164201150−18 Relay Interface Module •...
  • Page 144 Material and labor for external wiring requirements are to be provided by designated personnel. For external wiring, use 90°C copper wire for Powerware 9315 (200 kVA−300 kVA) UPMs and 90°C copper for Powerware 9315 (300 kVA−500 kVA) UPMs. See the appropriate column in Tables A and B.
  • Page 145 Table B. INPUT/OUTPUT Ratings & External Wiring Requirements for Powerware 9315 2000A System Bypass Module (SBM) Units Rating SBM Model 1200 1600 2000 Ratings Maximum Amps 1200 1600 2000 AWG or Refer to applicable Powerware AC Input from UPS to SBM CBS Breaker...
  • Page 146 Table C. Power Cable Terminations and Conduit Requirements Powerware 9315 1200A System Bypass Module Tightening Bolt/Int. Torque Hex Size Terminal Function Terminal Function Bus Landings N-M (lb-ft) (In.) Phase A 8 − 2 bolt mounting 76 (56) AC Input from UPS...
  • Page 147 Table D. Power Cable Terminations and Conduit Requirements Powerware 9315 2000A System Bypass Module Tightening Bolt Size Torque (In.) Terminal Function Terminal Function Bus Landings N-M (lb-in) Phase A 20 − 2-bolt mounting 76 (56) AC Input from UPS Output to SBM Phase B 20 −...
  • Page 148 (SBM) and optional equipment are crated separately for shipping. Do not tilt cabinets more than 10° during handling. Dimensions are in millimeters (inches). DESCRIPTION: INSTALLATION NOTES DRAWING NO: SHEET: 164201150−1 5 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−6 164201150 Rev. E www.powerware.com...
  • Page 149 Use supplied bus plate to connect 1200A SMB neutral to SBM neutral. Use supplied bus plates to connect the 2000A SMB inputs, bypass inputs, and neutral to the SBM. DESCRIPTION: INSTALLATION NOTES DRAWING NO: SHEET: 164201150−1 6 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−7 164201150 Rev. E www.powerware.com...
  • Page 150 Installation manual provided with the TYPICAL PARALLEL CAPACITY/ DESCRIPTION: UPMs, for UPM, battery, and optional REDUNDANT SYSTEM WITH 1200A SBM input transformer installation DRAWING NO: SHEET: 1 of 2 information. 164201150−2 EATON Powerware 9315 Parallel Capacity/Redundant System A−8 164201150 Rev. E www.powerware.com...
  • Page 151 Installation manual provided with the TYPICAL PARALLEL CAPACITY/ DESCRIPTION: UPMs, for UPM, battery, and optional REDUNDANT SYSTEM WITH 1200A SBM input transformer installation DRAWING NO: SHEET: information. 164201150−2 2 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−9 164201150 Rev. E www.powerware.com...
  • Page 152 Installation manual provided with the DESCRIPTION: TYPICAL PARALLEL CAPACITY/ UPMs, for UPM, battery, and optional REDUNDANT SYSTEM WITH 2000A SBM input transformer installation DRAWING NO: SHEET: information. 164201150−3 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−10 164201150 Rev. E www.powerware.com...
  • Page 153 Installation manual provided with the DESCRIPTION: TYPICAL PARALLEL CAPACITY/ UPMs, for UPM, battery, and optional REDUNDANT SYSTEM WITH 2000A SBM input transformer installation DRAWING NO: SHEET: information. 164201150−3 2 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−11 164201150 Rev. E www.powerware.com...
  • Page 154 UPS OUTPUT TO CRITICAL LOAD See Sheet 3 for notes. 3 PHASE, 3 OR 4 WIRE DESCRIPTION: ONELINE DRAWINGS OF PARALLEL CAPACITY/REDUNDANT SYSTEM DRAWING NO: SHEET: 164201150−4 1 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−12 164201150 Rev. E www.powerware.com...
  • Page 155 UPS OUTPUT TO See Sheet 3 for notes. CRITICAL LOAD 3 PHASE, 3 OR 4 WIRE DESCRIPTION: ONELINE DRAWINGS OF PARALLEL CAPACITY/REDUNDANT SYSTEM DRAWING NO: SHEET: 164201150−4 2 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−13 164201150 Rev. E www.powerware.com...
  • Page 156 Table I. Minimum Size Copper Bonding Jumper SBM Model Wire Size (kcmil) 1200A 1600A 2000A 2500A 3000A 4000A ONELINE DRAWINGS OF PARALLEL DESCRIPTION: CAPACITY/REDUNDANT SYSTEM DRAWING NO: SHEET: 164201150−4 3 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−14 164201150 Rev. E www.powerware.com...
  • Page 157 90.79 (3.57) CONTROL PANEL 1879.60 (74.00) 863.60 (34.00) 1200A SBM FRONT VIEW DESCRIPTION: 1200A SYSTEM BYPASS MODULE DRAWING NO: SHEET: 164201150−5 Dimensions are in millimeters (inches) 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−15 164201150 Rev. E www.powerware.com...
  • Page 158 CUSTOMER INTERFACE LANDING AREA PANEL 1879.60 (74.00) 1016.00 (40.00) 1200A SBM SIDE VIEW DESCRIPTION: 1200A SYSTEM BYPASS MODULE DRAWING NO: SHEET: Dimensions are in millimeters (inches) 164201150−5 2 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−16 164201150 Rev. E www.powerware.com...
  • Page 159 Installation manual provided with the UPMs, for UPM, battery, and optional input transformer DESCRIPTION: terminal locations. LOCATION OF 1200A SBM TERMINALS DRAWING NO: SHEET: 164201150−6 1 of 4 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−17 164201150 Rev. E www.powerware.com...
  • Page 160 Installation manual provided with the UPMs, for UPM, battery, and optional input transformer DESCRIPTION: terminal locations. LOCATION OF 1200A SBM TERMINALS DRAWING NO: SHEET: 164201150−6 Dimensions are in millimeters (inches) 2 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−18 164201150 Rev. E www.powerware.com...
  • Page 161 Installation manual provided with the UPMs, for UPM, battery, and optional input transformer DESCRIPTION: terminal locations. LOCATION OF 1200A SBM TERMINALS DRAWING NO: SHEET: 164201150−6 3 of 4 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−19 164201150 Rev. E www.powerware.com...
  • Page 162 Installation manual provided with the UPMs, for UPM, battery, and optional input transformer DESCRIPTION: terminal locations. LOCATION OF 1200A SBM TERMINALS DRAWING NO: SHEET: 164201150−6 Dimensions are in millimeters (inches) 4 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−20 164201150 Rev. E www.powerware.com...
  • Page 163 The SMB must be located and DESCRIPTION: attached to the right side of the SBM. 1200A SYSTEM MAINTENANCE BYPASS (SMB) DRAWING NO: SHEET: 164201150−7 1 of 2 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−21 164201150 Rev. E www.powerware.com...
  • Page 164 The SMB must be located and 1200A SYSTEM MAINTENANCE BYPASS (SMB) attached to the right side of the SBM. DRAWING NO: SHEET: 164201150−7 2 of 2 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−22 164201150 Rev. E www.powerware.com...
  • Page 165 The SMB must be DESCRIPTION: located and attached to the right side of the SBM. LOCATION OF 1200A SMB TERMINALS DRAWING NO: SHEET: 164201150−8 Dimensions are in millimeters (inches) 1 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−23 164201150 Rev. E www.powerware.com...
  • Page 166 The SMB must be located and attached to the right side of the SBM. DESCRIPTION: LOCATION OF 1200A SMB TERMINALS DRAWING NO: SHEET: 164201150−8 2 of 3 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−24 164201150 Rev. E www.powerware.com...
  • Page 167 The SMB must be located and attached to the right side of the SBM. DESCRIPTION: LOCATION OF 1200A SMB TERMINALS DRAWING NO: SHEET: 3 of 3 164201150−8 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−25 164201150 Rev. E www.powerware.com...
  • Page 168 90.79 (3.57) 2082.80 (82.00) OUTPUT BREAKER 1727.20 (68.00) 2000A SBM FRONT VIEW DESCRIPTION: 2000A SYSTEM BYPASS MODULE DRAWING NO: SHEET: Dimensions are in millimeters (inches) 164201150−9 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−26 164201150 Rev. E www.powerware.com...
  • Page 169 (FRONT) (FRONT) 2082.80 (82.00) 1016.00 (40.00) 1034.28 (40.72) 2000A SBM SIDE VIEW DESCRIPTION: 2000A SYSTEM BYPASS MODULE DRAWING NO: SHEET: Dimensions are in millimeters (inches) 164201150−9 2 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−27 164201150 Rev. E www.powerware.com...
  • Page 170 Installation manual provided with the UPMs, for DESCRIPTION: LOCATION OF 2000A SBM TERMINALS UPM, battery, and optional input transformer and terminal locations. DRAWING NO: SHEET: 164201150−10 1 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−28 164201150 Rev. E www.powerware.com...
  • Page 171 Installation manual provided with the UPMs, for DESCRIPTION: LOCATION OF 2000A SBM TERMINALS UPM, battery, and optional input transformer and terminal locations. DRAWING NO: SHEET: 164201150−10 2 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−29 164201150 Rev. E www.powerware.com...
  • Page 172 Installation manual provided with the UPMs, for DESCRIPTION: UPM, battery, and optional input transformer and LOCATION OF 2000A SBM TERMINALS terminal locations. DRAWING NO: SHEET: 164201150−10 3 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−30 164201150 Rev. E www.powerware.com...
  • Page 173 Installation manual provided with the UPMs, for DESCRIPTION: LOCATION OF 2000A SBM TERMINALS UPM, battery, and optional input transformer and terminal locations. DRAWING NO: SHEET: 164201150−10 4 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−31 164201150 Rev. E www.powerware.com...
  • Page 174 Installation manual provided with the UPMs, for DESCRIPTION: UPM, battery, and optional input transformer and LOCATION OF 2000A SBM TERMINALS terminal locations. DRAWING NO: SHEET: 164201150−10 5 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−32 164201150 Rev. E www.powerware.com...
  • Page 175 Installation manual provided with the UPMs, for DESCRIPTION: UPM, battery, and optional input transformer and LOCATION OF 2000A SBM TERMINALS terminal locations. DRAWING NO: SHEET: 164201150−10 6 of 6 EATON Powerware 9315 Parallel Capacity/Redundant System A−33 164201150 Rev. E www.powerware.com...
  • Page 176 DESCRIPTION: located. The SMB must be located and 2000A SYSTEM MAINTENANCE BYPASS (SMB) attached to the right side of the SBM. DRAWING NO: SHEET: 164201150−11 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−34 164201150 Rev. E www.powerware.com...
  • Page 177 The SMB must be located and attached to the right side of DESCRIPTION: the SBM. 2000A SYSTEM MAINTENANCE BYPASS (SMB) DRAWING NO: SHEET: 2 of 2 164201150−11 Dimensions are in millimeters (inches) EATON Powerware 9315 Parallel Capacity/Redundant System A−35 164201150 Rev. E www.powerware.com...
  • Page 178 The SMB must be located and attached to the right side of the SBM. DESCRIPTION: LOCATION OF 2000A SMB TERMINALS DRAWING NO: SHEET: 164201150−12 Dimensions are in millimeters (inches) 1 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−36 164201150 Rev. E www.powerware.com...
  • Page 179 The SMB must be DESCRIPTION: located and attached to the right side of the SBM. LOCATION OF 2000A SMB TERMINALS DRAWING NO: SHEET: Dimensions are in millimeters (inches) 2 of 4 164201150−12 EATON Powerware 9315 Parallel Capacity/Redundant System A−37 164201150 Rev. E www.powerware.com...
  • Page 180 The SMB must be located and attached to the right side of the SBM. DESCRIPTION: LOCATION OF 2000A SMB TERMINALS DRAWING NO: SHEET: 3 of 4 Dimensions are in millimeters (inches) 164201150−12 EATON Powerware 9315 Parallel Capacity/Redundant System A−38 164201150 Rev. E www.powerware.com...
  • Page 181 The SMB must be DESCRIPTION: located and attached to the right side of the SBM. LOCATION OF 2000A SMB TERMINALS DRAWING NO: SHEET: 4 of 4 Dimensions are in millimeters (inches) 164201150−12 EATON Powerware 9315 Parallel Capacity/Redundant System A−39 164201150 Rev. E www.powerware.com...
  • Page 182 DB−9 Connector Front Port 2 DB−25 Connector 1200 and 2000 Amp SBM Customer Interface Panel Top View DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 1 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−40 164201150 Rev. E www.powerware.com...
  • Page 183 POINT Arrangement C (Robust Network Routing) 1200 and 2000 AMP SBM TYPICAL POWERNET NETWORK DESCRIPTION: SBM CUSTOMER INTERFACE PANEL WIRING AND TERMINATIONS DRAWING NO: SHEET: 164201150−13 2 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−41 164201150 Rev. E www.powerware.com...
  • Page 184 120 ohm, 1/4 watt, 5% 120 ohm, 1/4 watt, 5% SBM and UPM PowerNet Interface Terminal Block Terminating Resistor Location DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 3 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−42 164201150 Rev. E www.powerware.com...
  • Page 185 Optional CAN Power Supply Panel with removable customer (A13) Terminal Block for Powerware wiring plug 9315 (500 kVA−750 kVA) Models only DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 4 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−43 164201150 Rev. E www.powerware.com...
  • Page 186 Default is On BLDG ALARM 6 RTN Generator. NOT USED NOT USED NOT USED NOT USED DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 5 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−44 164201150 Rev. E www.powerware.com...
  • Page 187 Terminal Block for Powerware 9315 +12VDC RTN (500 kVA−750 kVA) Models only +12VDC +12VDC RTN +12VDC +12VDC RTN DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 6 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−45 164201150 Rev. E www.powerware.com...
  • Page 188 Table L. Summary Alarm Relay Contacts RELAY 2 RELAY 1 CONTACT RATING: Maximum Switched Voltage 32 VAC 42 VDC Maximum Carrying Current DESCRIPTION: SBM CUSTOMER INTERFACE PANEL DRAWING NO: SHEET: 164201150−13 7 of 7 EATON Powerware 9315 Parallel Capacity/Redundant System A−46 164201150 Rev. E www.powerware.com...
  • Page 189 Refer to Tables M and N, and to applicable chapters for information about installing control wiring. UPM Powernet Interface Panel DESCRIPTION: UPM POWERNET INTERFACE PANEL POWERWARE 9315−200 TO −500 UPMs DRAWING NO: SHEET: 164201150−14 1 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−47 164201150 Rev. E www.powerware.com...
  • Page 190 INTERFACE PANEL Powerware 9315 (200 kVA−300 kVA) PowerNet Interface Panel Location DESCRIPTION: SBM CUSTOMER INTERFACE PANEL POWERWARE 9315−200 TO −500 UPMs DRAWING NO: SHEET: 164201150−14 2 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−48 164201150 Rev. E www.powerware.com...
  • Page 191 INTERFACE PANEL Powerware 9315 (400 kVA−500 kVA) PowerNet Interface Panel Location DESCRIPTION: SBM CUSTOMER INTERFACE PANEL POWERWARE 9315−200 TO −500 UPMs DRAWING NO: SHEET: 164201150−14 3 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−49 164201150 Rev. E www.powerware.com...
  • Page 192 Emergency Power Off control connections for UPMs. (Optional) EPO TO UPS MODULE DESCRIPTION: UPM POWERNET INTERFACE PANEL POWERWARE 9315−200 TO −500 UPMs DRAWING NO: SHEET: 164201150−14 4 of 4 EATON Powerware 9315 Parallel Capacity/Redundant System A−50 164201150 Rev. E www.powerware.com...
  • Page 193 164201150−13, sheet 2 for typical termination points. Refer to applicable chapters for information about installing control wiring. J2 CAN Interface Connection DESCRIPTION: UPM CAN INTERFACE: POWERWARE 9315−625/750 UPMs DRAWING NO: SHEET: 164201150−15 1 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−51 164201150 Rev. E www.powerware.com...
  • Page 194 CUSTOMER INTERFACE CAN B CAN A Powerware 9315 750 CAN A and CAN B Interface Location DESCRIPTION: UPM CAN INTERFACE: POWERWARE 9315−625/750 UPMs DRAWING NO: SHEET: 164201150−15 2 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−52 164201150 Rev. E www.powerware.com...
  • Page 195 Control power connection for Channel B CAN Logic Board from SBM. CAN B A1TB7-4 CONTROL POWER − GND J2−2 DESCRIPTION: UPM CAN INTERFACE: POWERWARE 9315−625/750 UPMs DRAWING NO: SHEET: 164201150−15 3 of 3 EATON Powerware 9315 Parallel Capacity/Redundant System A−53 164201150 Rev. E www.powerware.com...
  • Page 196 1 amp minimum if supplied by user. NOTE: This switch must be a dedicated switch, and not tied into any other circuits. DESCRIPTION: REMOTE EMERGENCY POWER OFF DRAWING NO: SHEET: 164201150−16 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−54 164201150 Rev. E www.powerware.com...
  • Page 197 (4.50) SQUARE Knockout pattern typ. 5 sides TO SBM TO OTHER EQUIPMENT DESCRIPTION: REMOTE EMERGENCY POWER OFF DRAWING NO: SHEET: Dimensions are in millimeters (inches) 2 of 2 164201150−16 EATON Powerware 9315 Parallel Capacity/Redundant System A−55 164201150 Rev. E www.powerware.com...
  • Page 198 BE TWISTED REMOTE MONITOR AND SBM NOT TO (14−18 gauge) EXCEED 500 FEET. DESCRIPTION: REMOTE MONITOR PANEL DRAWING NO: SHEET: Dimensions are in millimeters (inches) 164201150−17 1 of 1 EATON Powerware 9315 Parallel Capacity/Redundant System A−56 164201150 Rev. E www.powerware.com...
  • Page 199 500 feet. Wires must be twisted. MAX WIRE SIZE NO. 14 AWG. MIN WIRE SIZE NO. 18 AWG. DESCRIPTION: RELAY INTERFACE MODULE DRAWING NO: SHEET: Dimensions are in millimeters (inches) 164201150−18 1 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−57 164201150 Rev. E www.powerware.com...
  • Page 200 25.4 (1.00) 74.6 (2.94) 171.5 215.9 (6.75) (8.50) KNOCKOUTS PROVIDED ON FIVE SURFACES DESCRIPTION: RELAY INTERFACE MODULE DRAWING NO: SHEET: 164201150−18 Dimensions are in millimeters (inches) 2 of 2 EATON Powerware 9315 Parallel Capacity/Redundant System A−58 164201150 Rev. E www.powerware.com...
  • Page 201 CUSTOMER. MAX. DISTANCE BETWEEN BE TWISTED REMOTE MONITOR AND SBM NOT TO EXCEED 500 FEET. DESCRIPTION: SUPERVISORY CONTACT MODULE DRAWING NO: SHEET: 164201150−19 Dimensions are in millimeters (inches) 1 of 1 EATON Powerware 9315 Parallel Capacity/Redundant System A−59 164201150 Rev. E www.powerware.com...
  • Page 202 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System A−60 164201150 Rev. E www.powerware.com...
  • Page 203 Eaton−built accessories, and Powerware−built battery cabinets (individually and collectively, the "Warranted Items") are free from defects in material and workmanship. If, in the opinion of Eaton, a Warranted Item is defective and the defect is within the terms of this Warranty, Eaton’s sole obligation will be to repair or replace such defective item (including by providing service, parts, and labor, as applicable), at the option of Eaton.
  • Page 204 This Page Intentionally Left Blank. EATON Powerware 9315 Parallel Capacity/Redundant System 164201150 Rev. E www.powerware.com...
  • Page 206 *164201150E* 164201150 Rev E...

Table of Contents
