Front Fan Assembly
Description
Front fan assembly
1.
Prepare the computer for disassembly
2.
Remove the access panel
3.
Remove the cables from the clip on the top of the fan assembly.
Figure 7-25
4.
Unplug the fan cable from the system board connector labeled CHFAN.
(Computer Access Panel on page
Removing the cables from atop the front fan assembly
(Preparation for Disassembly on page
123).
Spare part number
585884-001
75).
Front Fan Assembly 147
