Velocity Tails

In the Drum Grid pane, you have the option of showing the velocity of each note as a series of bars. The
higher the bars, the higher the velocity value.
Notes with velocity showing
Notes without velocity showing
To Display Velocity Tails in the Drum Grid Pane
• Click the Show/Hide Velocity Tails button
Or
• Press the Y key.

Editing Note Velocities

In the Drum Map Editor you can display note velocities as a series of horizontal bars behind the note.
Click the Show/Hide Velocity Tails button
To Edit a Note Velocity in the Drum Grid Pane
1. Click the Draw tool button
2. Move your cursor over the velocity tail you want to edit until the cursor changes to look like this:
3. Click and drag the velocity tail. Drag it up to increase the velocity. Drag it down to decrease the
velocity.
To Edit Multiple Note Velocities in the Drum Grid Editor
When you edit multiple notes that have different initial velocities, the velocities are adjusted on a
relative basis, so if you reduce a velocity by 50%, all other selected notes have their velocities reduced by
the same percentage. For example: you select three notes. The first has a velocity of 100, the second a
velocity of 50, and the third a velocity of 30. You click and drag the velocity of the first note down to 50.
The second note's velocity changes from 50 to 25 and the third note's velocity changes from 30 to 15.
1. Select the notes you want to change the velocity of.
2. Click the Draw tool button
3. Move your cursor over one of the selected notes.
4. Hold down the Shift key.
5. Click and drag the velocity tail. Drag it up to increase the velocity. Drag it down to decrease the
velocity.
in the Piano Roll view toolbar.
to display note velocities.
.
.
309
