When the Event List view includes more than one track, events are mixed together in chronological
order. For example, if you select tracks 1 and 3 when you open the Event List view, you see a single list
of intermingled events from tracks 1 and 3. You can have any number of Event List views, each
containing any number of tracks, open at the same time. You can change the tracks shown in the Event
List view by clicking the

Event List Buttons and Overview

Each line of the Event List view shows a single event along with all of its parameters. There are many
different types of events. All share the following parameters:
• The time of the event, displayed in SMPTE (hours:minutes:seconds:frames) format
• The time of the event, displayed in MBT (measures:beats:ticks) format
• The event type, or kind of event
The remaining parameters vary by event type. You can hide or show each kind of event by clicking its
button in the Event List toolbar or by checking its checkbox in the Event Manager dialog box. Here is a
summary listing of the parameters that apply to each type of event.
Short name and
display button...
Note
KeyAft
Control
Patch
ChanAft
Wheel
RPN
NRPN
Sysx Bank
Sysx Data
Text
Lyric
290
button and choosing the tracks you want.
Type of event...
MIDI note
MIDI key aftertouch
MIDI controller change
MIDI patch change
MIDI channel aftertouch
MIDI pitch wheel position
Registered Parameter
Number
Non-registered Parameter
Number
System Exclusive data bank
System Exclusive data
message
Text
Lyric
Parameters...
Pitch (MIDI key number), velocity (0-127),
duration (beats:ticks or simply ticks), MIDI
channel (1-16)
Pitch (MIDI key number), pressure amount (0-
127), MIDI channel (1-16)
Controller number (0-127), controller value (0-
127), MIDI channel (1-16)
Bank select method, bank number, number or
name of the patch, MIDI channel (1-16)
Pressure amount (0-127), MIDI channel (1-16)
Wheel position (-8192 to 8191, where the center
is 0)
Parameter number (0-16383), parameter value
(0-16383), MIDI channel (1-16)
Parameter number (0-16383), parameter value
(0-16383), MIDI channel (1-16)
Sysx bank number (0-8191)
Sysx message up to 255 bytes long
Text
Text (a single word or syllable)
