APPENDIX A - ACCESSORIES AND SPARE PARTS
A.2 ACCESSORIES
A.2.1 Belt coupler
In the s'print-B battery model, there is a support kit available for the printer that consists of a belt and
fastening screws. The figure below illustrates how the belt coupler is attached underneath the printer.
