Turning the printer On and Off using software commands
If the printer is off, sending a characters set on the serial line will turn it on
in the diagram below:
NOTE
(2)
It's not possible to turn
on the printer sending one
or more characters through
the infrared device.
(3) NOTE
The printer start up will not
occur before 200-250 msec.
This delay is caused by
internal component.

1.2 BATTERIES

1.2.1 Recharging batteries

Appearing in the printer set up print out (see sec. 1.3) is the parameter HEAD VOLT that gives the battery
charge level.
To recharge the batteries (4)
connect the battery recharger jack to the cable jack (vedi fig. 1.4) and plug the battery recharger into the
electrical mains;
connect the cable RJ11 connector to the RJ11 connector located under the printer (see fig. 1.4). For a com-
plete recharge, we recommend that the batteries be left to charge for two hours;
DPT100-B/I/BT
No
, use the cable packed with the printer and proceed as follows:
1. INSTALLATION AND USE
. Follow the instructions shown
(2)(3)
START
Time out = 10 sec.
Transmits status
command
Yes
RTS is high ?
No
Yes
Received characters
from serial
No
Time out = 0?
Yes
Printer on
error
END
1- 2
(Fig.1.3)
Printer
on
(Fig.1.4)
