Table 25 Equipment switch settings (unit control board)
Switch OFF Position
1 Compressor
2 Staged Reheat
3 Not Used--Must remain in OFF position
4 Not Used--Must remain in OFF position
5 Enable Reheat
6 Enable Humidifier
7 Enable Dehumidifier
8 Electric Reheat
Table 26 Switch settings (wall box board)
Switch OFF Position
1 Disable Beeper
2 Not Used--Must remain in OFF position
3 Not Used--Must remain in OFF position
4 Not Used--Must remain in OFF position
5 Not Used--Must remain in OFF position
Compressor on continuously
6
for tight control
7 Disable Setback
8 Enable Password
ON Position
Chill Water
SCR Reheat
Disable Reheat
Disable Humidifier
Disable Dehumidifier
Gas Reheat
ON Position
Enable Beeper
Economy Mode
Enable Setback
Disable Password
