Table 19 Dimensions and net weights—air-cooled outdoor condensing units
Model Numbers
60Hz
PFH027A-L
PFH027A-H
PFHZ27A-L
PFH037A-L PFH036A-L
PFH037A-H PFH036A-H
PFHZ37A-L PFHZ36A-L
Source: DPN000130, Rev. 1
5.7.2

Piping Connections

Details for Refrigerant (R-407C) Loop piping are in 5.5.3 - Piping Connections and Coolant
Requirements.
5.7.3

Electrical Connections

Refer 5.5.5 - Electrical Connections for general wiring requirements and cautions. Refer to
electrical schematic when making connections.
Power Connections
The outdoor condensing unit requires its own power source and earth ground, with a disconnect
switch (field supplied) to isolate the unit for maintenance. A transformer is available for 277 VAC,
single phase, applications (2- and 3-ton).
Control Connections
Field-supplied control wires must be connected between the evaporator and the condensing unit. (See
Figure 16 and the electrical schematic on the units for more details.) Four wires are required
between the evaporator and condensing unit.
Dimensions, inches (mm)
50Hz A
— 40 (1016) 23-1/2 (597)
—
— 48 (1219) 31 (787)
53 (1343) 36-1/4 (918)
Module Net
B C
18 (457)
18 (457) 241 (109)
18 (457) 351 (159)
35
Site Preparation and Installation
Weight
lb (kg)
200 (91)
®
Liebert
™
Mini-Mate2
