6.2 Main Menu <Menu>
Press the MENU key to display the Main Menu. The Menu selections (in the following order) include:

SETPOINTS

STATUS
ACTIVE ALARMS
TIME
DATE
SETBACK
SETUP OPERATION
SETPOINT PASSWORD
SETUP PASSWORD
Use the Up/Down arrow to scroll through the selections. When ready to select a particular function
press Enter.
6.3 Setpoints
Setpoints and system setup parameters are kept in nonvolatile memory. Selecting SETPOINTS from
the Main Menu will display the following selections:
• TEMPERATURE SETPOINT
• TEMPERATURE SENSITIVITY
• HUMIDITY SETPOINT
• HUMIDITY SENSITIVITY
• HIGH TEMPERATURE ALARM
• LOW TEMPERATURE ALARM
• HIGH HUMIDITY ALARM
• LOW HUMIDITY ALARM
Scroll through this submenu by using the Up/Down arrow, then press Enter to select a particular
function. To change a particular value, press Enter and use the Up/Down arrows to change the value.
When the value has been changed press Enter to store the value. For example to change the
temperature setpoint from the main status display.
1. Press the Menu key to display the main menu.
2. Scroll to "SETPOINTS" using the Up/Down arrow key. Press the Enter key.
3. Scroll to "TEMP SETPOINT" using the Up/Down arrow key. Press the Enter key.
4. Use the Up/Down arrow to change the value. Press the Enter key.
Table 21 View default setpoints and allowable ranges
Setpoint
Temperature Setpoint
Temperature Sensitivity
Humidity Setpoint
Humidity Sensitivity
High Temperature Alarm
Low Temperature Alarm
High Humidity Alarm
Low Humidity Alarm
® ™
Liebert Mini-Mate2
CALIBRATE SENSORS
ALARM ENABLE
ALARM TIME DELAY
COMMON ALARM ENABLE
CUSTOM ALARMS
CUSTOM TEXT
DIAGNOSTICS
END OF MENU
Default Range
72°F 40-90°F (5-32°C)
2.0°F 1-9.9°F (0.6-5.6°C)
50% 20-80% RH
5% 1-30% RH
80°F 35-95°F (2-35°C)
65°F 35-95°F (2-35°C)
60% 15-85% RH
40% 15-84% RH
44
Microprocessor Control
