Figure 14 Dimensions, evaporator units with optional belt drive blower assembly

16-13/16" (427mm)
Threaded Rod Centers
19" (483mm)
Blower Box
Dimension
9-3/4" Outlet
(248mm)
5-7/8"
(149mm)
6-7/8" (175mm)
6-5/16" (160mm) Outlet
4-29/32" (125mm)
Threaded Rod
To Threaded Rod
Table 16 Net weight, high static blower module
Unit
High Static
Blower Module
Source: DPN000194, Rev. 3
29-7/8" (759mm)
Threaded
Rod Centers
30" (762mm)
Blower Box
Dimension
High Static
Blower
Module
3-7/32"
(82mm)
Base to
Base
Net Weight
lb (kg)
85 (39)
57-13/16" (1468mm)
Overall Dimension
55-13/16" (1418mm)
Threaded Rod Centers
4-29/32" (125mm)
Cabinet to Cabinet
54" (1372mm)
Cabinet Dimension
14"
(356mm)
Outlet
Dimension
25
Site Preparation and Installation
Evap
Unit
24" (610mm)
30" (762mm)
Cabinet
Dimension
18 "
(457mm)
Outlet
Dimension
DPN000194
Rev. 3
®
Liebert Mini-Mate2
Cabinet
Dimension
™
