■ Supplied accessories

Microphone Microphone hanger
and screw set
DC power cable Function name
stickers*
Mounting bracket Flat washers
Spring washers
Nuts
* 1
Used for labelling the programmable
function keys according to their
assinged functions.
* 2
Used for optional unit installation.
Ask your dealer for details.
Microphone
hanger cable
2
Sponges*
1
Bracket bolts
Mounting screws
(5×12)
Self-tapping screws
(5×16)
CONNECTION AND MAINTENANCE

■ Mounting the transceiver

The unversal mountng bracket suppled wth your trans-
cever allows overhead or dashboard mountng.
• Mount the transcever securely wth the 4 suppled screws
to a thck surface whch can support more than 1.5 kg.
Flat washer
Felt*
Spring washer
Felt*
When using
self-tapping screws *Felt reduces the effects of vibration.
