Parts Manual; Initial Parts Kit (P/N 4001.50) - CMA Dishmachines L-1C Parts Manual

1. Parts Manual

1.1.

Initial Parts Kit (P/N 4001.50)

P/N
00120.02
00200.75
00206.70
00208.40
00304.04
00308.50
00404.82
00411.00
00415.00
00425.51
00425.53
00471.10
00501.00
00715.00
02257.00
02257.22
03406.64
03415.00
03415.60
03470.01
03604.30
04103.00
04110.00
04113.00
04303.00
04517.15
NOTE: CMA recommends that the initial parts kit be kept on hand as a back up supply of critical parts
in the event your machine should require emergency service. All the parts included in this kit
are unique to the L-1C dishmachine.
MODEL L-1C PARTS MANUAL Rev. 1.17A
DESCRIPTION
Bi Metal Thermometer 1.5"
Pump Assy, 110/220V 60 Hz, Open
Pump Seal Kit
Slip Joint Nut Gasket
Spray Arm Short B- L1X-L1X16
Spray Arm End Plug SS
Motor Contactor Relay
Micro Switch
Peristaltic Pump Assembly, 120V/60Hz
Chemical Tubing Blue
Chemical Tubing Red
Toggle Switch DPST 20 Amp
Timer Motor, 2-Minute
1/2 Ball Check Valve
Squeeze Tube 8" Norprene
Squeeze Tube 22" Norprene For L-1X
Drain Toggle Switch
Chemical Tube Bulkhead
Chemical Bulkhead Assy.(Teflon)
Toggle Switch(Moment) .25 Flat Term
Dema Valve Repair Kit 1/2"
L-1C Drain Valve, 120V
SS L1-C Drain Screen
Drain Valve 115V New style
Spray Arm Bearing (L1X/GLX)
Door Stop Undercounter (Parallel)
Parts Manual
Qty
1
1
1
1
1
1
1
1
1
50 ft.
50 ft.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
