- Page 1 MODEL CMA-66 PARTS MANUAL Rev 1.06A C M A D I S H M A C H I N E S 1 2 7 0 0 K N O T T A V E N U E GARDEN GROVE, CALIFORNIA 92841 8 0 0 - 8 5 4 - 6 4 1 7 F A X 7 1 4 - 8 9 5 - 2 1 4 1 www.cmadishmachines.com...
-
Page 2: Table Of Contents
Table of Contents PARTS MANUAL... 4 1.1. Initial Parts Kit (P/N 13996.80)... 4 1.2. Exploded View Drawings... 5 1.2.1. Cabinet Assembly ... 5 1.2.2. Control Box Assembly ... 6 1.2.3. Curtain and Optional Vent System ... 7 1.2.4. Temperature Control System ... 8 1.2.5. -
Page 3: Parts Manual
1. Parts Manual 1.1. Initial Parts Kit (P/N 13996.80) 00201.85 Pump Motor, 1HP, 3Ph, 60 Hz, 220V 00206.00 Pump Seal Kit 00208.00 Slip Joint Nut Gasket 00411.00 Micro Switch 00421.83 CMA-66 Power Rocker Switch, Red 00421.87 CMA-66Heater Rocker Switch, White 00557.30 Kynar Reed Switch Gray, 110/220V, 12’... -
Page 4: Exploded View Drawings
1.2. Exploded View Drawings 1.2.1. Cabinet Assembly ITEM REQ’D 13903.36 Frame Stand 13902.35 L-R Pan 13902.45 R-L Pan 13900.36 L-R Wrapper 13900.46 R-L Wrapper 01506.30 Door 13901.00 Wrapper Shield 01554.30 Door Guide 00636.10 Door Guide Plastic 13915.00 Door Latch Bracket 00535.30 Door Handle 00905.00... -
Page 5: Control Box Assembly
1.2.2. Control Box Assembly ITEM REQ’D 13904.06 Control Box w/Lid 13012.26 Motor Contactor, 220V 13003.50 Contactor, 30-Amp 03202.00 Thermometer 03202.08 Thermometer Bracket 00454.06 6-Pole Terminal Block 13003.70 Timer Relay Override Switch 00470.10 Toggle Switch Rubber Boot 13003.60 Starter DIN Rail MODEL CMA-66 Part Manual rev. -
Page 6: Curtain And Optional Vent System
1.2.3. Curtain and Optional Vent System ITEM REQ’D 13912.82 Splash Shield 13702.25 Curtain, 20-5/8” x 15” 13702.15 Curtain, 20-5/8” x 11” 13702.30 Curtain, 24-5/8” x 15” 13704.26 Double Curtain Splash Guard Bracket 13705.00 Curtain Rod, Short 13705.10 Curtain Rod, Long MODEL CMA-66 Part Manual rev. -
Page 7: Temperature Control System
1.2.4. Temperature Control System ITEM REQ’D 13417.80 Immersion Heater, 3Ph, 240V, 10kW* 13463.10 Liquid Level Switch, SS 13417.89 Thermostat 12KW Heater 03202.00 Thermometer 13463.50 Liquid Level Switch Shield * Includes P/N 13417.89 Thermostat w/c can be ordered separately MODEL CMA-66 Part Manual rev. 1.05 01/11/05 ITEM DESCRIPTION DESCRIPTION... -
Page 8: Pump Assembly
1.2.5. Pump Assembly ITEM DESCRIPTION REQ’D 00201.85 Pump Motor, 1HP, 3Ph, 60 Hz, 220V 03224.00 Pump Base Mount 00206.00 Pump Seal Kit 03226.00 Pump O-Ring Gasket 03222.85 CMA-66 Water Pump Impeller 04206.00 Pump Cover 00208.00 Slip Joint Nut Gasket 04204.00 Compression Nut, 2.5”... -
Page 9: Drain System Assembly
1.2.6. Drain System Assembly ITEM REQ’D 13001.85 Drain Manifold 20500.06 Waste Drain Valve 01317.17 1-1/2” x 2” No Hub 03001.82 Drain Pipe Support Bracket 50109.00 Hose Clamp MODEL CMA-66 Part Manual rev. 1.05 01/11/05 ITEM DESCRIPTION DESCRIPTION REQ’D 00912.00 1/4-20 Lock Nut 00924.00 1/4“... -
Page 10: Plumbing System Assembly
1.2.7. Plumbing System Assembly ITEM REQ’D 03603.15 1/2” Water Solenoid Valve 220V, JE* 00738.15 Water Solenoid Valve Coil, 220V, ½” & ¾” 03603.20 1/2” Water Solenoid Valve Bonnet 00707.00 1/2” Water Solenoid Valve Repair Kit 03614.00 1/2” Close Nipple, Brass 41030.10 1/2”... -
Page 11: Wash System Assembly
1.2.8. Wash System assembly ITEM REQ’D 13305.06 Spray Arm End Cap 13327.06 Socket Bracket, Double 13327.26 Socket Bracket, Single 13303.06 Spay Arm 04306.10 Square Manifold Gasket 13310.00 1/2” Cap, Brass 13304.30 Final Rinse Spay Arm* 13304.56 Final Rinse Spray Jets, SS 13618.00 1/2”... -
Page 12: Rocker Arm Assembly
1.2.9. Rocker Arm Assembly ITEM REQ’D 13570.20 Conveyor Drive Assy, 220V, 60Hz, 3Ph* 13501.85 Motor, 1/3HP, 220V, 60Hz, 3Ph 13504.00 Gear Reducer, Right 13504.12 Gear Reducer, Left 13505.10 Rocker Arm Cam 13507.50 Cam Bearing, SS 13816.00 5/16-18 x 1/2" Socket Set Screw 13505.20 Keyway Cam 13829.10... -
Page 13: Trip Switch Assembly - Old Style
1.2.10. Trip Switch Assembly – Old Style ITEM REQ’D 13408.85 Trip Switch Assembly* 13424.50 Trip Switch Bearing 13455.00 Switch Sleeve, Brass 13435.00 Bearing Nut 13409.51 Shaft Extender, Threaded 13411.00 Lock Ring 13825.00 8-32 x 1” Pan Head Screw *Includes Items 2, 3, 4 and 8. MODEL CMA-66 Part Manual rev. -
Page 14: Trip Switch Assembly - New Style
1.2.11. Trip Switch Assembly – New Style ITEM REQ’D 13408.61 Actuator Arm 00907.50 6-32 x 3/8” Pan Head Screw 00557.70 Reed Switch Magnet (SS) 13408.62 Actuator Bracket 00557.56 Reed Switch 13408.63 Reed Switch Bracket 00965.00 6-32 Nylon Lock Nut 00924.00 ¼”... -
Page 15: Paddle Switch Assembly
1.2.12. Paddle Switch Assembly ITEM REQ’D 13409.86 Paddle with Magnet, R-L 13409.89 Paddle with Magnet, L-R 13409.87 Paddle Support Brackets 00557.56 Kynar Reed Switch 13409.30 PS Reed Switch Bracket 00914.00 1/4-20 x 3/4" Hex Head Bolt 00912.00 1/4-20 Nylon Lock Nut MODEL CMA-66 Part Manual rev. -
Page 16: Table Limit Switch Instructions (P/N 13469.20)
2. Table Limit Switch Instructions (P/N 13469.20) MODEL CMA-66 Part Manual rev. 1.06 01/11/05 Page... - Page 17 12 FT 24 FT Instructions: 1. Determine the approximate centerline of the dish rack as it travels down the clean table. 2. Place the template from the template kit (6) with the lower edge resting on the table surface, against the end roll, and centered along the dish rack’s line of travel.
-
Page 18: Corner Feed Table (Optional Factory Installed Only)
3. Corner Feed Table (Optional factory installed only) MODEL CMA-66 Part Manual rev. 1.05 01/11/05 Page... - Page 19 MODEL CMA-66 Part Manual rev. 1.05 01/11/05 Page...
-
Page 20: Drain Water Tempering Kit (Optional)
4. Drain Water Tempering Kit (Optional) MODEL CMA-66 Part Manual rev. 1.06 01/11/05 Page...
