Parts Manual; Initial Parts Kit (P/N 4001.00) - CMA Dishmachines GL-X Parts Manual

1. Parts Manual

1.1.

Initial Parts Kit (P/N 4001.00)

P/N
00200.10
00206.30
00208.40
00304.03
00308.50
00404.82
00411.00
00415.00
00421.40
00425.51
00425.53
00425.54
00458.00
00501.00
00556.10
00715.00
02257.00
02257.30
03415.00
03415.60
03480.00
03604.30
04110.00
04113.00
04303.00
04305.10
04517.15
NOTE: CMA recommends that the initial parts kit be kept on hand as a back up supply of critical
parts in the event your machine should require emergency service. All the parts
included in this kit are unique to the GL-X glasswasher.
MODEL GL-X PARTS MANUAL Rev. 1.04
DESCRIPTION
Pump Assy, 110/220V 60 Hz, Open
Pump Seal Kit
Slip Joint Nut Gasket
Spray Arm B GL-X
Spray Arm End Plug SS
Motor Contactor Relay
Micro Switch
Peristaltic Pump Assembly, 120V/60Hz
Fill/Start Rocker Switch
Chemical Tubing Blue
Chemical Tubing Red
Chemical Tubing White
Squeeze Tube, Black (Detergent)
Timer Motor, 2-Minute
Reed Switch, ISI
1/2 Ball Check Valve
Squeeze Tube, 8", Silicone
Squeeze Tube, 30"
Chemical Tube Bulkhead
Chemical Bulkhead (Teflon) Assy
Drain Rocker Switch
Dema Valve Repair Kit 3/8",1/2" & 3/4
SS L1-C/L-1X Drain Screen
GL-X Drain Valve, 120V
GL-X Spray Arm Bearing
Red Silicone Gasket, 1/16 Thick
Door Stop (Parallel)
Parts Manual
Qty
1
1
1
1
1
1
1
1
1
50 ft.
50 ft.
50 ft.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Page
3
