Chapter 1: Introduction to D-Command
Welcome to the D-Command™ worksurface for Digidesign®
ICON systems.
D-Command provides hands-on control of Pro Tools®, and
offers powerful options for customizing the Pro Tools mix en-
vironment.

D-Command Features

The D-Command system provides controls for most Pro Tools
recording, editing and mixing tasks, and a versatile re-
mote-controlled audio monitoring system.
Control Features
• Touch-sensitive, motorized 100mm faders
• Touch-sensitive, multi-purpose rotary controls
• Dedicated controls for assignment and activation of inputs,
outputs, inserts and sends
• Flexible display of pan, insert, send, plug-in and mic pre
controls
• Dedicated EQ and dynamics plug-in control sections
• Dedicated controls for all channel strip functions including
recording and input monitoring modes, mute, solo, and
channel select
• Dedicated controls for automation mode, enable and safe
status
• Custom Fader Mode for flexible channel and parameter
mapping
• Full transport and navigation controls, including location
commands and scrub/shuttle capability
Monitoring Features
• 6-channel control room monitoring system supports mono
through 5.1 surround monitoring, with up to 5 possible in-
put sources and 3 selectable output paths
• 2-channel cue system with 4 separate outputs and selectable
talkback feed
• Built-in talkback microphone and external talkback mic In-
put
• Standalone mode for monitoring without Pro Tools
• External source metering

D-Command System Components

The following components are included in a D-Command
8-channel or 24-channel system:
Main Unit
• D-Command Main Unit
• AC power cord
• Ethernet cable
• Ethernet "crossover" cable (for direct connection to CPU
without a hub)
• Ethernet loopback plug (for Ethernet testing)
• 9/64-inch hex driver (for removing side panels)
• 5/32-inch hex driver (for connecting Main Unit and
Fader Module)
Fader Module
(Required for 24-Channel System)
• D-Command Fader Module unit
• AC power cord
• Ethernet cable
XMON Monitoring System
• XMON Interface
• AC power cord
• XMON cable

System Expansion Options

An additional 16-channel Fader Module can be added to
D-Command, for a total of 24 faders. For details on D-Com-
mand expansion and customization options, visit the Digide-
sign Web site (www.digidesign.com).
