Global Controls Section

The Global Controls section (Figure 2) is a set of channel-re-
lated controls in the center of the D-Command Main Unit.
Flip
Auto Write
Start
Automation Write
controls
All
End
Flip
Auto Enable
Plug-in
Automation Enable
Vol
controls
Pan
Mute Send Mute
Mute
Sw Mode
Sw Info
Escape
Sel
Mode
Solo Clear
Do to Sel Do to All
Disp Mode
Susp Grp
Focus Channel
&
Custom Faders
Custom Fader
Groups
controls
Type
Plug-In
Bank / Cycle
Auto Mode
Automation Mode Write
controls
Touch
Latch
Talkback
Dbl Press to Latch
Figure 2. Global Controls section
Flip
switches
Current
All Enab
Send Lvl
Send Pan
Pre
Switch Information
controls
Show Val
Foc
Global Modifier
controls
Default
Auto Susp
Map
Lock
Window
Trim
Read
Off
Talkback switch
Flip Switches
The two yellow Flip switches in the Global Controls section
correspond to the two rotary encoders on the D-Command
channel strips.
Flip Mode
The Flip switches invoke Flip mode, which transfers controls
from the corresponding rotary encoder to the fader on each
channel strip, allowing convenient editing and automation of
send, pan, plug-in, and mic pre parameters directly from the
channel faders.
In Flip mode, the rotary encoder control swaps with the chan-
nel fader; the encoder Select switch swaps with the channel
Select switch; the encoder Bypass/Mute/Pre switch swaps with
the channel Mute switch; and the encoder display swaps with
the channel display.
In Flip mode, the Flip switch lights for the affected row of en-
coders, and the yellow Flip LED below each affected encoder is
lit.
To transfer controls from a row of rotary encoders to the channel
faders:
Press the Flip switch that corresponds to the encoder row.
■
To exit Flip mode:
Press a lighted Flip switch.
■
When D-Command is in Flip mode and you enter Make
Inactive mode or Assign mode, it is temporarily taken out
of Flip mode, but the Flip switch remains lit. When you
exit Make Inactive mode or Assign mode, controls return
to their flipped positions.
Automation Write Controls
The Automation Write controls invoke the manual "Write to
Start/End/All" commands, the automatic "Write to
Start/End/All on Stop" automation commands, and the
"Write to Current Parameter" and "Write to All Enabled Pa-
rameters" snapshot automation commands in Pro Tools.
Auto Write
Start
Automation
Write to All
switch
All
Automation
Write to End
switch
End
Automation Write controls
Automation
Write to Start
switch
Write to Current
Parameter
switch
Current
Write to All Enabled
Parameters
switch
All Enab
Chapter 6: Channel Strip Controls 35
