Surround Inputs
Surround Inputs
Signal Name
Surround Input 1 (L)
[Surround Input 2 (Lc)]*
Surround Input 3 (C)
[Surround Input 4 (Rc)]*
Surround Input 5 (R)
Surround Input 6 (Ls)
Surround Input 7 (Rs)
Surround Input 8 (LFE)
GND
SHIELD GND
* Surround Inputs 2 and 4 are active on XMON, but the corre-
sponding Lc and Rc outputs cannot be controlled indepen-
dently from the D-Command monitor section.
Stereo Inputs
Stereo Inputs
Signal Name
Stereo Input 1 (Left)
Stereo Input 1 (Right)
Stereo Input 2 (Left)
Stereo Input 2 (Right)
Stereo Input 3 (Left)
Stereo Input 3 (Right)
[Not Connected]
[Not Connected]
GND
SHIELD GND
110
D-Command Guide
Hot (+)
Cold (–)
Ground (shield)
24
12
25
10
23
11
21
9
22
7
20
8
18
6
19
4
17
5
15
3
16
1
14
2
13
connector housing
Hot (+)
Cold (–)
Ground (shield)
24
12
25
10
23
11
21
9
22
7
20
8
18
6
19
4
17
5
15
3
16
1
14
2
13
connector housing
Cue Outputs
Cue Outputs
Signal Name
Hot (+)
SLS Output (Left)
24
SLS Output (Right)
10
Cue Output 1 (Left)
21
Cue Output 1 (Right)
7
Cue Output 2 (Left)
18
Cue Output 2 (Right)
4
[Not Connected]
15
[Not Connected]
1
GND
SHIELD GND
Main Speaker Outputs
Main Speaker Outputs
Signal Name
Hot (+)
Main 1 (L)
24
[Main 2 (Lc)]*
10
Main 3 (C)
21
[Main 4 (Rc)]*
7
Main 5 (R)
18
Main 6 (Ls)
4
Main 7 (Rs)
15
Main 8 (LFE)
1
GND
SHIELD GND
* Main Speaker Outputs 2 and 4 are active on XMON, but Lc
and Rc outputs cannot be controlled independently from the
D-Command monitor section. Global Volume, Solo, and
Mute controls affect all outputs.
Cold (–)
Ground (shield)
12
25
23
11
9
22
20
8
6
19
17
5
3
16
14
2
13
connector housing
Cold (–)
Ground (shield)
12
25
23
11
9
22
20
8
6
19
17
5
3
16
14
2
13
connector housing
