(Fig. 9-10)
(Fig. 9-11)

9.3 Setting a satellite position

For each satellite position to be entered, work through Points 9.3.1 to
9.3.3. When programming satellite positions, we recommend that you
begin with the satellite in the most easterly position, then work your
way through all the remaining positions in a westerly direction, finis-
hing off with the most extreme westerly satellite position. Your digital
receiver is pre-programmed at the factory for the most commonly
used satellite positions. In addition, you can configure user-defined
satellite positions (User 1 to User 14) for every possible orbital posi-
tion.

9.3.1 Selecting a satellite position

9.3.1.1 Selecting a pre-programmed satellite
position
> To accept a satellite position in the satellite list, use the
arrow keys to mark the field Sat new.
> Confirm by pressing OK.
A list with all the available satellite positions will be displayed.
(Fig. 9-10)
> Now use the arrow keys up/down to mark a satellite
position you would like to accept into the satellite list.
> Press OK to accept the selection.
With the Geo-positioning function set to On (Point 9.2), the dish
will now automatically be rotated to the programmed satellite
position. The rotation procedure will be indicated by a blinking dis-
play "turn".
If the Geo-positioning function is switched Off, (Point 9.3.2.2)
you will have to turn the dish manually to the desired satellite
position.

9.3.1.2 Setting a user-defined satellite position

(User satellite)

> To accept a user satellite position into the satellite list, use
the arrow keys to mark the field Sat new.
> Confirm by pressing OK.
A list showing all available satellite positions will be dis-
played. (Fig. 9-11)
> Now use the arrow keys to mark a user satellite position
(User 1 to User 14).
> Confirm by pressing OK , the menu for setting the test trans-
ponder will be displayed. In this menu, enter the data for the
test transponder as well as that of the LNC in use, as
described in Point 6.4.3.
