Power Switch

The power switch is a circuit breaker located in the lower right corner of the
right front door of the LSM.
Lift the switch to supply power to the robot and the drives.
Make sure that all jobs being performed by the drives and robot are complete,
then push down on the switch to remove power to the drives and the robot.
Figure 2-5

Figure 2-5. Power Switch Location

shows the power switch location.
A
Power Switch
POWER
SWITCH
DETAIL A
H_C60155
2-9
